Cat5e UTP Outdoor Network Cable

Product Description

Applications:
Twisted-pair cable such as Cat5e or Cat6 is a type of cabling that is used for phone systems and most modern
Ethernet networks.

A pair of wires forms a circuit in order to transmit data. The pairs are twisted to provide protection against crosstalk, which is the noise generated by adjacent pairs.

CAT-5e
This cable is used for networks and mulit-line phone systems. It has a maximum frequency of 350 MHz and can transmits up to 10/100/1000Mbps. Category 5 Enhanced (CAT-5 E) will work with ANSI/TIA/EIA 568A and ANSI/TIA/EIA 568B. It is the current standard for installing networks.

Each cable is fully tested, quality inspected, and meets all TIA/EIA Cat5e standards. Constructed from high quality copper cable, this design minimizes Near-End Crosstalk (NEXT) levels, and provides universal connectivity for LAN network components such as PCs, computer servers, printers, routers, switch boxes, network media players, NAS, VoIP phones, PoE devices, etc
Configuration:

Inner conductor	Material	Soild Bare Copper/CCA
	Diameter	0.5 ± 0.01mm (24AWG)
Insulation(Dielectric)	Material	Color-coded PE (Polyethylene)
	Thickness	≥ 0.18mm
	Diameter	0.91± 0.01mm
Twisted pair	4Pairs	Pair 1 : Blue, White / Blue Pair 2 : Orange, White / Orange Pair 3 : Green, White / Green Pair 4 : Brown, White / Brown
Shild	Material	PET Film
Rip Cord	N/A	Yes
Outer Jacket	Material	PE/LSZH
	Thickness	≥ 0.50mm
	Nominal O.D	5.0mm ± 0.20mm
Options: Jelly Compound, Jacket: UV, FR, Rohs complied.

Mechanical Properties:

Elongation	Min. 300%
Temperature Range	-20 up to +75° C
Tensile Strength	Min 1.68kg/mm²

Electrical Properties:

Conductor Resistance	Max. 9.5 ohm/100m
Resistance Unbalance	Max. 2%
Insulation Resistance	150 ohm/KM
Mutual Capacitance	Max. 5600pF/100m
Capacitance Unbalance	Max. 330pF/100m
Impedance	100+/-15 ohm
Spark Test	2000V
Velocity of Propagation	67%
Standard	UL444,TIA/EIA568B,ISO/IEC11801

Technical Performance:

Frenquency	Attenuation	RL	Next	PS Next
(Mhz)	(dB/100M)	(dB)	(dB)	(dB/100m)
1MHz	2.0	20.0	65.3	62.3
4MHz	4.1	23.0	56.3	53.3
8MHz	5.8	24.5	51.8	48.8
10MHz	6.6	25.0	50.3	47.3
16MHz	8.2	25.0	47.3	44.3
20MHz	9.3	25.0	45.8	42.8
25MHz	10.4	24.3	44.3	41.3
31.25MHz	11.7	23.6	42.9	39.9
62.5MHz	17.0	21.5	38.4	35.4
100MHz	22.0	20.1	35.3	32.3

Packing & Shipping
(1) Packing Lengths:3m/5m/10m/20m/50m/100m/200m/305m/500m/1000m etc
(2) Inner Packing:Polybag,Blister,Shrink Wrap,Wooden reel,Plastic reel,or Cardboard drum
(3) Outer Packing:Carton box,Pull out box,Pallet available
(4) Other packing available according to clients' request
(5) Usually we deliver our products by SEA.
Other delivery methods are available upon request from clients.
Our Service:
1) Quick Response --All inquiries will be replied within 24 hours.
2) Professional Quotation --All prices will be quote according to customers' detailed
specifications & requirements.
3) OEM & ODM Service
4) Can print your own brand on the jacket printing with foot or meter marking.
5) Make customized designs for stickers, drums, outer cartons, etc.
6) Stable Quality --All materials and products passed restrict QC procedures,comply with
international standards.
7) Fast Delivery --LCL orders,15days after confirmation; FCL orders, 20 days after
Confirmation in usual.
Good After-sales Service
--We chose the fastest vessel to POD for delivery our goods to clients,
--All Documents will be issued according to clients' instructions, to save troubles from local customs.
--Any complaint to quality or packing issued will be responded, and terminated with proper solutions for clients.

FAQ:
Q1: What kind of cable do you produce?
A: We specialized in producing Coaxial Cable,Network Cable,Patch Cord,CCTV Cable,Optical Fiber Cable, Speaker Cable,Alarm Cable,Telephone Cable,Drop Wire,Audio Cable,HDMI Cable,Control Cable etc
We also supply cable accessory products such as connector, cable clip,cable tie,crimping tool, antenna dishe,splitters,amplifer,optical receiver,optical transmitter etc

Q2: What's your MOQ? Can you offer free samples?
A: Our MOQ is 10KM per item. Free samples can be sent to you if available in stock,freight cost need to be paid by your side.

Q3: What's your delivery time?
A: Normally, our delivery time is 15 days after received deposit,it base on the quantity of the order.

Q4: What's your payment term?
A: We accept T/T, L/C,Western Union.Other payments accept through negotiation.

Q5:What's your trade term?
A: We accept FOB ShangHai or Ningbo,CFR,CIF,EXW term

Q6: Where is your factory located? How can I visit there?
A: Our factory is located inLin'An HangZhou City,ZheJiang Province,China.
1 hour drive from HangZhou XiaoShan International Airport
3 hours drive or 1 and half an hour by high speed rail to railway station from shanghai or Ningbo

---
