Product Details
Product Description
Product Description
Product Description
FZX Self Washing Type Vibration Screen Machine adopts a new type of screening equipment with a spring supporting screen frame to improve the running balance of the vibration screen. It is widely used in removing joints and coarse selection of pulping processes such as mechanical wood pulp, sulfate wood pulp, straw pulp and waste paper. When used for removing the section, it can be installed after the washing process. When used for coarse selection, it is installed before the washing process. The motion curve of the machine is O type. It has the advantages of large vibration amplitude, strong screening ability, high working efficiency, low noise, easy operation, low maintenance rate and low consumption and energy-saving, etc. It is an ideal equipment for screening and purification of pulp removal, slag removal and slurry in modern paper industry.
Item Model
| FZX-1.0
| FZX-2.0
| FZX-3.0
| FZX-4.0
|
Production capacity(t/d)
| 4~13
| 7~20
| 15~45
| 18~60
|
Screening area(m2)
| 1.0
| 2.0
| 3.0
| 4.0
|
Diameter of screen hole(mm)
| φ2~φ6mm
|
Diameter of screen seam(mm)
| H0.15-1.5mm
|
Frequency of vibration(times/minute)
| 960r/min
| 780r/min
|
Concentration of inflow pulp(%)
| 1-1.5
|
Concentration of output pulp(%)
| 0.8-1
|
Power of motor(kw)
| 3kw/6level
| 5.5kw/6level
| 7.5kw/6level
| 7.5kw/8level
|
Packaging & Shipping
Our Services
Fangyuan Zhonghe has a complete sales service system, which is composed of marketing, distribution management, direct sales business, technical support, after-sales service, regional development and other parts of the network throughout the country. These network nodes form an organic whole with the company headquarters and serve the users wholeheartedly.
Packaging & Shipping
Company Information
Shandong Fangyuan Zhonghe Machinery Co., Ltd(Formerly Zhucheng Fangyuan Machinery Co., Ltd) is the backbone enterprise specializing in the production of environmentally-friendly pulping equipment, tissue paper machine and sewage treatment equipment, the main products include two categories, more than 50 series, the production of paper pulp making equipment, such as FZX Self Washing Type Vibration Screen Machine, sewage treatment equipment and crescent type tissue paper machine, with high technical content, it has reached the domestic advanced level in the same industry.
Fangyuan Zhonghe adhere to the business purpose and policy of "custom is the first" and "unity and pragmatism, striving for excellence", introduces the modern science and technology and management methods, and constantly introduce excellent talents and modern equipment, breaks through innovation, strives for excellence, the excellent quality makes company's products develop continuously in the fierce market competition. The FZX Self Washing Type Vibration Screen Machine we manufactured were sold well all over the country and exported to Southeast Asia, Central Asia, Africa and other countries and regions.
With the rapid development of the national economy and the requirement of the sustainable development and harmonious development, environmental protection is playing a more and more important role. China's environmental protection industry is facing unprecedented opportunities for development. To improve the living environment of mankind and write a brilliant chapter of Chinese environmental protection industry, we will make unremitting efforts and have succeeded in carrying out an assignment. Our company warmly welcomes friends and business colleagues all over the world to come and guide us in creating a better future for environmental protection.
Q1. Are you a manufacturer?
A: Yes, we have been concentrating on this series of products for 20 years' experience
Q2. How to proceed an order for the FZX Self Washing Type Vibration Screen Machine from factory?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production and shipping.
Q3. How to pay?
A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balance before loading by TT.
Q4. What is the delivery time?
A: It depends on order quantities. Generally speaking, the delivery time will be finished before the guarantee date.
Q5: Do you offer guarantee for the FZX Self Washing Type Vibration Screen Machine?
A: Yes, under the right condition , we offer different time warranty for our products.
Q6. How to pack the FZX Self Washing Type Vibration Screen?
A: Standard oversea packages or according to customer's requirement will be used.
If you have special package requirements, we will pack as required, but the fees will be paid by
customers.
Q7. How to install the FZX Self Washing Type Vibration Screen after arriving destination?
A: We will provide detailed drawings to you. If it is necessary, we will send technical engineers to help you. However, the visa fee, air tickets, accommodation, wages will be paid by buyers.
>>
