Product Description
Product Description
Details of ProductTmeasurement Magmaster Pcb Board Of Electromagnetic Flow Meter Transmitter outline dimension and typeAccording to the size of the sensor, we offer four kinds of transmitter housing, As shown in the figure below, please note: the PCB board, software and menus and functions are be the same, only the size of housing and shape of the housing is differentSeperated type flow transmitterTransmitter menu structureThe menu structure of mag meter sensor is as shown in the following figure:Key point of attentionThe flow meter is installed correctly on the pipe to ensure the straight pipe section and the installation position and the grounding to meet the requirements. As shown in the following figure:Ralationship between battery life and meter sensor sizeIf your meter transmitter size is big ,and need long battery life , then need install external battery and different size ,the external battery capacity is different. If the size is greater then DN600, then the internal battery life is short than 26 months, so suggest use external battery. Battery life tableBattery Type Battery LifeSize ≤ DN150DN150 ≤ Size ≤ DN350DN400 ≤ Size ≤ DN600Internal Battery33 months30 months26 monthsExtrenal Battery72 months72months72 monthsSuitable to Size of the Sensor (mm):1,2,3,6,8,10,15,20,25,32,40,50,65,80,100,125,150,200,250,300,350,400,450,500,600,650,700,800,900,1000,1100,1200,1300,1400,1500,1600,1700,1800,2000,2200,2400,2600,2800,3000Power SupplyPower supply :85VAC --- 265VAC or or 110VAC to 420VAC or 24VDC or 3.6v lithium batteryRequirement For Sensor And Excitation (AC and DC power supply type)Excitation current can be set to 125mA,160mA,250mA 250mA excitation current is suitable to the resistance of two coil: 35~ 65ohm125mA excitation current is suitable to the resistance of two coil: 65 ~ 120ohmexcitation frequency:25HZ;12.5HZ,6.25HZ,3.125HZ CommunicationRS485 (standard),HART (option) MODBUS interface:RTU format,Physical interface:RS-485,Electrical isolation:1000V; HART interface:Support standard HART protocolCertificationsRelated Products Intergrated Type Flow MeterFT8210H electromagnetic flowmeter,flow converterclick here to the productSeperated Type Flow Meterelectromagnetic flowmeter manufacture,flow converterclick here to the productHow to place orderOur Service1. 18 Month's Warranty.2. Delivery time:3-7 working days after payments received3.Packaging Detail:Carton4.According to purchases Qty,can choose by air or sea5. MOQ:1 set.6. Service express company:TNT/DHL/FedEX.7. We accept T/T, Western Union, PayPal & Secure Payment.Our CompanyDalian Taijia Technology Co., Ltd.Dalian Taijia Technology Co.,Ltd is a high technology company which specializes in supplying and supporting of ultrasonic measurement equipment. prime products include ultrasonic transit-time flow meter, ultrasonic level meter, ultrasonic thickness meter etc. Our products are widely used in water supply and drainage water, petroleum and chemicals, food and pharmaceutical.We have sold product in more than 30 countries, such as America. Italy. India. Korea. Germany. Canada. Australia etc.Click here to our home page.Contact US
>>
