US$70,000.00-100,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Machining Process
Hydraulic
Vibrating Amplitude
2.4mm
Certification
ISO9001: 2000, CE
Max. Vertical Conveying Distance
61.1m
Max. Horizontal Conveying Distance
55.9m
Concrete Pumping Pressure
8.6MPa
Theoretical Pumping Times
21~23times/Min
Transport Package
Bulk Cargo Shipping
Specification
15200*2500*4000mm
Production Capacity
500pieces/Year
Product Description
Specification
Description
| Unit
| Parameter value
|
Outline dimension
| mm
| 15200×2500×4000
|
Overall weight
| kg
| 49000
|
Chassis
| Model
|
| Actros4141 8×4
|
Manufacturer
|
|
|
Max. speed
| km/h
| 85
|
Max. grade-ability
| %
| 51.4
|
Wheelbase
| mm
| 2300+4000+1350
|
Engine
| Model
|
| OM501LA·IV/3
|
Max. power
| kW
| 305
|
Max. torque
| N·m/(r/min)
| 2000/1080
|
Displacement
| L
| 11.946
|
Emission standard
|
| Eruo IV
|
Pumping system
| Theoretical output
| m³/h
| 170
|
Concrete pumping pressure
| MPa
| 8
|
Theoretical pumping times
| Time/min
| 21~23
|
Delivery cylinder diameter ×stroke
| mm
| φ260×2200
|
Max. diameter of pumping concrete
| mm
| ≤40
|
Filling height
| mm
| 1540
|
Concrete slump range
| cm
| 8~23
|
Placing boom
| Reach height
| m
| 61.1
|
Reach depth
| m
| 43.6
|
Slewingradius
| m
| 55.9
|
Slewing angle
| °
| ±270
|
Unfolding angle of the 1st section
| °
| 90
|
Unfolding angle of the 2nd section
| °
| 180
|
Unfolding angle of the 3rd section
| °
| 180
|
Unfolding angle of the 4th section
| °
| 240
|
Unfolding angle of the 5th section
| °
| 210
|
Unfolding angle of the 6th section
| °
| 90
|
Stabilizer span
| Longitudinal span of stabilizer
| mm
| 12125
|
Transverse span of front stabilizer
| mm
| 12125
|
Transverse span of rear stabilizer
| mm
| 12200
|
Others
| Lubrication method
|
| Automatic lubrication
|
Control method
|
| Manual/remote control
|
Volume of water box
| L
| 1000
|
Company Profile
FAQ
1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.
3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
>>
