Stainless Steel Cr Sheet Galvanized Sheet Cutting to Length Machine Ce Certificated

US$12,000.00-18,000.00 1 set (MOQ)

Basic Info.

Model NO.

customized

Drive Mode

CNC

Warranty

1 Year

Customized

Layout

Horizontal

Cutting Material

Carbon Steel, Aluminum, Metal Alloy, Stainless Steel

Automatic Grade

Automatic

Power Source

Electric

Cutting Mode

Waterjet Cutting

Application

for Cold Rolled Steel Coil, Galvanzied

Thickness

0.3mm to 1.8mm

Width

400mm to 1000mm

Coil ID

508mm

Coil Od

No More Than 1500mm

Coil Weight

10ton Max

Sheets Length

500mm ~ 5000mm

Stacking Height

Max 400mm

Stacking Weight

Max 5000kg

Transport Package

Sea Shipping

Specification

20′′ container

Trademark

SENERGE

Origin

Shanghai, China

Production Capacity

3 Unit/ Month

Product Description

Stainless Steel CR Sheet Galvanized Sheet Cutting to length Machine CE certificated
1.1 Input Material
Cold rolled steel coil, Galvanized steel ,coil,Stainless steel
Thickness: 0.4mm to 3.0mm
Width: 1000mm to 1600mm
Coil ID: 508mm/610mm
Coil OD: ≤Φ1600mm
Coil weight:15,000kg Max
1.2 Cut to Length Performance
Sheets length: 300mm ~4000mm
Length Tolerance: +/-0.5mm (For Length 2000mm)
Diagonal Accuracy: ≤+/-0.8mm/2m (JIS standard sheet)
Flatness: ≤3I (JIS standard sheet)
Stacking Weight: 5T
1.3 Slitting Performance
Strips Number (related to the thickness of the strip):
7 cuts(thickness 3mm)
14 cuts(thickness 2mm)
Width Accuracy: 0.1mm
Cutting Burr: 5% sheet thickness,
Slitting Straightness: 0.5mm/1000mm
Recoiling Weight: Max 15T (DIA<1600)
