| US$3,000.00-11,000.00 | 1 Set (MOQ) |
| 8 Main Parts Of chicken farm equipment | |
| Chiken Farm Equipment Name: | Main Function: |
| 1 Environment Control System | A variety of environment controllers are customized from Israel,it can reach a most advanced control leave in poultry house control. |
| 2 Main Feed Line System | Silo /manpower hopper is the beginning of main feed line.There is a feed sensor at the end of main feed line which controls motor on and off to achieve automatic feed delivery. |
| 3 Pan Feeding Line System | There is a feed sensor at the end of each feeding line which controls motor one and off to achieve automatic feed delivery to each feed pan. |
| 4 Automatic Drinking Line | Supply clean water to each nipple steady, chicken can drink water from 360 degree freely |
| 5 Ventilation System | Make chicken shed keep suitable temperature for different stage chicken |
| 6 Cooling Pad System | The longitudinal way of cooling-fan ventilation way is the most economical and effective way to reduce temperature of chicken house in summer. |
| 7 Heating System | In winter or chicks,it make chicken house has a suitable temperature. |
| 8 Fogging And Disinfection | It is effectively tools for cooling,damping,dedusting and disinfecting the house |
| Option 1: Feed silo | 6.2m3-11.2m3-16.4m3-21.6m3-32m3-42m3 Double layer galvanized steel sheet Life more than 10 years |
| Option 2: Manpower hopper | 800-1200kg volume Double-layers Galvanized Steel Sheet with film Life more than 10 years |
| Driving Motor | Power:0.75kw or 1.5kw Voltage:220v/380v |
| Feed level Sensor: | Germany IFM feed level sensor |
| Feed conveying pipe: | Diameter:75*3.6mm Material:PVC |
| Helical spring auger: | Imported from South Africa |
| Vice hopper: | 90kg GI material hopper |
| Conveying pipe: | 4-pan/3m or 3-pan/3m Diameter:45mm Thickness:1.2mm Material:hot-dip galvanized steel pipe zinc coating 275g/M2 |
| Helical spring auger: | Imported from South Africa |
| Pan feeder: | Many kinds of feeder for you choose Made by origin plastic to make it strong |
| Feeder sensor: | Germany IFM feed level sensor |
| Driving sensor: | Taiwan motor Special motor with reduction gear together |
| Suspension system: | Winch,pully,fixing plate,steel rope and clamp Convenient to adjust the height |
| Nipples: | Outer material:engineering plastic Inner material:stainless steel Double-sealing structure with good seal ability 360 degree movable to drink |
| Pressure regulator: | Double barreled with large flow capacity Regulating stability Water supply is sufficient |
| Water display level tube: | Sturdy and durable Easy to take down and clean |
| Doser: | Add medicine automaticlly Economical and reliable Easy to control and maintain,good corrosion resistance |
| Lifting and suspension system: | Winch,pully,fixing plate,rope adn clamp Convenient to adjust the height |
| 50" Centrifugal Butterfly Cone Fan | Power:1.1kw Air flow:49453m3/h Dimension:1380x1380x450 Open mode:centrifugal push-pull |
| 50" Centrifugal Fan | Power:1.1kw Air flow:43170m3/h Dimension:1380x1380x450 Open mode:centrifugal push-pull |
| 36" Centrifugal Fan | Power:0.4kw Air flow:20800m3/h Dimension:1000x1000x450 Open mode:centrifugal push-pull |
| Air Inlet Window | Strong anti-aging ability,longer service Wind deflector can prevent cold wind Double spring ensure excelling sealing Flexible opening with anti-bird nets |
