1. Front bezel aluminum alloy brushed metal craft, seamless design, front panel IP65 waterproof.
2. Industrial LCD panel, wide operating temperaturer: -20 ~ 70 °C, wide viewing angle, high nits, true color.
3. Adopt multi-points PCAP touch panel, high sensitive and fast-response.
4. Cover with AG glass, Anti-glare.
5. EETI touch controller.
6. High performance motherboard, 7x24 continuous operation.
7. Ultra-thin front bezel 3mm, ideal for embedded mounting.
PC
|
CPU
| Intel® Celeron J1900, quad core, 2.0GHz, fanless
|
Chipset
| Intel ValleyView SSA-CUnit
|
Memory
| 2G DDR3 (4G, 8G optional)
|
Hard Drive Capacity
| 64G SSD
|
Hard Drive Optional
| SSD: 32G, 128GB, 256GB
|
HDD: 500GB, 1TB
|
Graphics
| CPU Integrated graphics HD Graphics and support 1080p HD photo quality
|
Audio
| Realtek ALC662, High Definition Audio (HD), Line in, Line out
|
Network
| 1×Realtek RTL 8111E Gigabit Ethernet controller
|
Wireless Network
| WIFI
|
I/O Interface
| 2×USB 2.0, 2×USB 3.0, 2 x COM RS232
|
1×VGA/HDMI/RJ45/Audio OUT/MIC IN/POWER DC
|
Operation System
| Support Windows 7/8/10, Linux, Ubuntu, Debian etc.
|
LCD panel
|
Panel size
| 7"
|
Resolution
| 1024*600
|
Aspect ratio
| 16:9
|
Support Color
| 16.7M colors
|
Brightness (cd/m²)
| 1000 nits, sunlight readable
|
Response time
| 5ms
|
Contrast ratio
| 800:1
|
View angle
| 75°/75°/75°/75° (R/L/U/D)
|
Touch panel
|
Touchscreen Type
| Project Capacitive Touch (10 points)
|
Touch Interface
| USB (RS232 optional)
|
Touch response time
| 2ms
|
Luminousness
| 90%
|
Surface Hardness
| 7H
|
Working life
| >50 million times
|
Touch options
| (5 wire resistive touch, IR touch optional)
|
Power Supply
|
External Power Supply
| AC 100 - 240V
|
Working voltage
| DC 12V
|
Power consumption
| ≤45W
|
Enclosure
|
Material
| Aluminum Alloy bezel+ High strength cold rolled steel back case
|
Color
| Silver, Black, white, color can be customized
|
VESA mounting
| 75×75mm
|
IP grade
| front panel IP65 waterproof
|
Operating Environment
|
Temperature Range
| operating: -20 to 70°C, storage: -30 to 80°C
|
Relative humidity
| 5%~95% @ 40° C, non-condensing
|
Vibration
| 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
|
Packing Details
|
Net weight
| 1.5kg
|
Gross weight
| 2kg
|
Product Dimension
| 20.11*13.66*5.05cm
|
Packing size
| 40*33*16cm
|
Accessories
| Power adapter, embedded screws, user manual, warranty card
|
Other
|
Mounting (options)
| embedded mounting screws
|
wall mounting brackets (optional)
|
desk stand holder (optional)
|
Warranty
| 1 year warranty
|
