Basic Info.
Pressure
Ordinary Pressure
Seal Surface
Wedge Gate Valve
Thread Position of Valve Rod
Inside Gate Valve
Application
Industrial Usage, Water Industrial Usage, Household Usage
Transport Package
Small Box-Cartons-Plywood Case
Production Capacity
5000/Month
Product Description
Gate valve 200WOG
Features
Stainless Steel one piece Seat
Various Thread Standards Available
Using dewaxing precision casting
Product standard
Design: ASME B16.34
Wall Thickness: ASME B16.34
Pipe Thread: ASME B1.20.1, BS21, DIN 2999/259, ISO 228/1, JIS B 0203, ISO 7/1
Inspection & Testing: MSS SP-110, EN 1226
| No. | Parts name | Material |
| ANSI/JIS/DIN | ANSI/JIS/DIN |
| 1 | Body | A351-CF8M/SCS14A/1.4408 | A351-CF8/SCS13A/1.4308 |
| 2 | Disc | A351-CF8M/SCS14A/1.4408 | A351-CF8/SCS13A/1.4308 |
| 3 | Stem | SUS316 |
| 4 | Cap | A351-CF8M/SCS14A/1.4408 | A351-CF8/SCS13A/1.4308 |
| 5 | Cap gasket | PTFE/RPTFE/PPL |
| 6 | Circlip for shaft | SUS304 |
| 7 | The Gasket | SUS304 |
| 8 | Stem packing | PTFE/RPTFE/PPL |
| 9 | Washer | SUS304 |
| 10 | Packing nut gland | A351-CF8M/SCS14A/1.4408 | A351-CF8/SCS13A/1.4308 |
| 11 | Wheel Handle | Aluminum |
| 12 | Elastic gasket | SUS304 |
| 13 | Hexagon nut | A194-8 |
| Size | L | H | E |
| 1/2" | 55 | 93 | 70 |
| 3/4" | 60 | 105 | 70 |
| 1" | 65 | 115 | 80 |
| 1-1/4" | 75 | 130 | 80 |
| 1-1/2" | 85 | 145 | 100 |
| 2" | 95 | 170 | 100 |
| 2-1/2" | 106 | 200 | 125 |
| 3" | 116 | 218 | 125 |
>>
