Hydraulic Circular Hole Concrete Diamond Wire Sawcutting Machine

US$9,500.00
1-4 Pieces
US$9,000.00
5-9 Pieces
US$8,500.00
10+ Pieces

Basic Info.

Model NO.
YG-600
Type
Hydraulic Cutting Machine
Usage
Concrete Curb
Application
Machinery & Hardware, Construction
Source Voltage
380V
Automation
Automatic
Cutting Ability
High Speed
Control
Artificial
Certification
CE
Product Name
Wire Saw
Item
Electric Wall Saw
Feature
High Frequency
Keyword
Mini Wire Saw Machine
Power
16kw
Blade Dia
600-1200mm
Max. Cutting Depth
530mm
Saw Head Weightg
38K
Voltage
220V/380V
Control Unit Weight
17kg
Wireless Control Range
Below 300m
Packing
Wooden Case
MOQ
1set
Motor Cooling Method
Air Cooling
Oil Flow Rate
30-80L/Min
Transport Package
Wooden Case
Specification
1500*800*1200mm
Trademark
YG
Origin
Henan
HS Code
8202991000
Production Capacity
100set/Month

Product Description

Product Description

Hydraulic Diamond Wire Saw Circular Hole Concrete Cutting Machine
Hydraulic wire saw machine (wire saw) uses the oil pressure of the hydraulic pump station to drive the hydraulic motor to rotate. The hydraulic motor drives the driving wheel to rotate, and the driving wheel drives the rope to rotate. At the same time, the rope is guided by the driven wheel to control the direction of the rope to rotate at high speed, thereby achieving the purpose of cutting the steel bars. Concrete cutting for demolition purposes. This equipment can achieve various cuttings of thicker concrete. It is generally used in the static cutting and removal of bridges, piers, dock platforms, and underwater concrete piles to ensure that the original structure is not damaged.
Features of Diamone wire saw machine
1. High efficiency, capable of cutting underwater and cutting irregular objects
2. There is no need for a large amount of cooling water. Anyone who has used a hydraulic wire saw knows that the hydraulic pump station must use cooling water to cool the oil temperature to reduce the problem. The electric wire saw does not need a large amount of cooling water, only the rope head is needed. Just add cooling water and it can work for a long time.
3. Low cost: It can be operated with household electricity, eliminating the need for a hydraulic system, so the cost is much lower. Product Parameters
wire drive mode hydraulic rated output power 22/25kw
mode type HM-40/80 working voltage 380v50Hz
minimum input power 25HP or 33HP hydraulic pump station gear pump
output shaft speed 350/940/1300r/min motor working flow 40-100L/min
maximum wire length 18m working pressure 15-20Mpa
feeding method fully hydraulic oil tank volume 16L

Detailed Photos
