Photovoltaic System Easy Use Solar 1500V DCJunction Box

Product Details

Product Description

Product Description
Place of Origin
Guangdong, China
Brand Name
NSPV
Model Number
Middle Junction Box
External Size
-
Box material
PPE/PA
Rated current
22A(Diode 30A)
35A(Diode 50A)
Rated voltage
1500VDC
Test voltage
6kV(50Hz,Imin)
Typical contact resistance
≤ 0.25mΩ
Contact material
Copper,Tin plated
Degree of protection
IP68(in potting)
Safety degree
II
Flame class
UL94-V0
Ambient temperature range
-40℃...+85℃(IEC)
Photovoltaic System Easy Use Solar 1500V DCJunction Box

---
