| model Parameter | mechanical valve series | peristaltic pump series | ||||
| PMS2T | PMS2P | PMS3T | PMS3P | PMP2C | Mini-PMP1C | |
| Push rod type | pressure rod type | push rod type | pressure rod type | |||
| Number of valve ports | 2 | 3 | 2 | 1 | ||
| Climate type | SN | |||||
| Anti electric shock protection | I | |||||
| Power supply | AC220V~,50Hz | |||||
| Rated current (A) | 0.30 | 0.60 | 0.30 | |||
| Rated power (W) | 60 | 80 | 60 | |||
| Power consumption (kW. h/24h) | 0.55 | 0.78 | 0.60 | |||
| Total effective volume (L) | 33 | 31 | 25 | 11 | ||
| Storage temperature (ºC) | 0~8 | |||||
| Refrigerant and filling amount | R600a,29g | R600a,19g | ||||
| Foaming agent | C-P/I-P | |||||
| Noise dB (A) | 40 | |||||
| Number of valve ports and packaging of raw materials | 2×10L | 3×7.5L | 2×10L | 1×10L | ||
| External dimensions (mm) | width 435 x depth 525 x height 885mm | width 300 x depth 525 x height 707mm | ||||
| Net weight (Kg) | 35 | 36 | 40 | 29 | ||
