Noblest Cryogenic Liquid Oxgen Tank 20FT

Product Description

Description:Micro Bulk Tank
The NOBLEST Micro Bulk Tank is a state-of-the-art, compact cryogenic liquid storage solution featuring a robust fixed base and high vacuum multi-layer insulation. With capacities ranging from 1 to 5m³ and pressures up to 3.6Mpa, this innovative tank has revolutionized the gas supply industry by supplanting traditional steel and Dewar cylinders. Enjoy hassle-free operation with minimal liquid waste and no need for frequent cylinder replacements. Ideal for applications in cutting, welding, cryogenic laboratories, hospitals, and more, our micro bulk tank ensures reliable performance and convenience.
With professional
technology, NOBLEST offers cutting-edge micro bulk tank products to meet the highest standards of excellence.
Specifications:

Design Temperature:	-196ºC~50ºC
Volume:	2~250m3 or Customized
Medium:	Liquid oxygen,argon,nitrogen,LNG,CO2,ethylene,etc
Working pressure:	0.2~3.5Mpa or customized
Placement Type:	Vertical or Horizontal
Certification:	ASME, GB150,CE
Insulation Method:	Vacuum powder/ Polyurethane foam/ High vacuum winding
Brand:	NOBLEST
Lead Time:	30 working days
Material:	Stainless steel / Carbon steel

Advantages:
★ High vacuum winding insulation design with auxiliary high-efficiency vacuum technology for superior heat insulation and reduced liquid evaporation.
★
Large diameter body design with low vertical transport height, ensuring optimal performance and cost-effective transportation.
★
Compact main structure with a small footprint, allowing for quick and convenient installation.
★
Neat and clear pipe layout; top of the tank features a unified forging welding structure to prevent leaks caused by thermal expansion and contraction.
★
Optional features include aflow meter
and remote monitoring capabilities, enabling comprehensive digital and information management.

---
