| US$3,000.00-3,600.00 | 1 Piece (MOQ) |
| Model# | XR-980 | XR-506 | XR506-3 | ||||||
| Conveyor Height from Ground (can be customized) | 680mm ± 30mm | 680mm ± 30mm | 680mm ± 30mm | ||||||
| Memory function | Store 100 product parameters | Store 207 product parameters | 207 product parameters | ||||||
| Operation Panel Languages | English, Spanish, Portuguese, Turkish, Japanese, Chinese | English, Spanish, Japanese, Chinese | English, Spanish, Japanese, Chinese | ||||||
| LCD Screen | 3.2''LCD screen with push buttons | 7'' Full Color touchable screen | 7'' Full Color touchable screen | ||||||
| Tunnel width(mm) | 400(Standard ) ;Customized(Nonstandard) | ||||||||
| Tunnel height(mm) | 100 | 120 | 150 | 200 | 250 | 300 | 350 | 400 | |
| Detection Sensitivity | Fe(mm) | ≥0.6 | ≥0.8 | ≥1.0 | ≥1.5 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 |
| Non-Fe (mm) | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | |
| SUS304 (mm) | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | ≥4.5 | |
| Material of Construction | SUS 304 | ||||||||
| Conveyor Belt | Standard: White PVC Belt Optional: Food-grade white PU belt | ||||||||
| Conveyor Direction | From left to right (face to the operation panel) | ||||||||
| Power Supply | Alternating current 110V/120V/380V(+10%,-15% 50/60Hz) | ||||||||
| Buttons | Standard: Emergency Stop Button Optional: Start/Stop Buttons | ||||||||
| Working Temperature | 0ºC - 40ºC | ||||||||
| Humidity | Below 90% Relative humidity (without condensate) | ||||||||
| Customized service | 1.Detection Tunnel Size; 2.Rejection system: Pusher, Air jet, Drop down and Diverter for optional; 3.Conveyor direction; 4.Conveyor belt: Food grade white belt, Plate chain conveyor; 5. Conveyor Speed: Consistent / Adjustable; 6. USB Data Exporting. | ||||||||
| Remark | The actual performance may be subject to working environment and components of the products to be tested. | ||||||||
