Good Quality Observation Panoramic Passenger Elevator Lift

Product Description

FUJI High Speed Full Glass Sightseeing Panoramic Elevator
Digital variable frequency technology
It can implement speed regulation, reduce the elevator vibration to the lowest extent, rigorously and effectively controls the noise.
Long-distance monitor functions
It perfectly combines network with mobile communication functions, comprehensively fulfills internet long-distance monitor.
Highly intergrated intellectual control system
It increases date processing speed with the more perfect function and the more accurate car shift.
Superior Car Wall
It adopt highly secure safety laminated glass. It is transparent. The passengers might appreciate the busy and prosperous city sight through the transparent car wall.
Lamination layer in laminated glass resists radiation. It buffers sound-wave vibration and isolates the sound. Large area car wall glass design shows smooth and beautiful lines.
It beautifies the elevator car outline. Furthermore, the buildings are more attractive.
Outer Glass Hood
It harmoniously combines with the building and surroundings. Panoramic elevator is part of the building. It also adds a mobile charming scene for the building.
Fiber G lass Reinforced Plastic Construction
It perfectly displays an overall compact and beautiful space. It can carry out different construction layout designs. It is prompt and convenient. Round halfround, square etc. are available for your free choice.

Load(kg)	Hoistway size
	min width(mm)	Max width(mm)	Min depth(mm)		Door-open size(mm)
800	2400	2700	2080	1950	800x2100
1000	2500	2800	2330	2150	900x2100
1150	2550	2850	2430	2250	900x2100
1350	2750	3050	2430	2250	900x2100
1600	2750	3050	2730	2250	900x2100

Panoramic Elevator Construction Layout Drawing
Our factory
Delivery
About us
Why choose us?
Shanghai Sunny Elevator Co., Ltd, founded in 1992, is a 32-years professional manufacturer specializing in designing and producting Opto-Electro-Mechanical products.
Sunny Elevator has started import and export since 2012.
We have experience for exporting all kinds of elevator & elevator parts to 80 countries all over the world.
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won't break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.

---
