| US$120,000.00-145,000.00 | 1 Piece (MOQ) |
| Engine | |
| Model | Isuzu/Cummins |
| Type | Six-cylinder,water-cooled turbocharged,mechanical injection |
| Rated power | 106KW |
| Main Technical Specification | |
| Operating weight | 40000Kg |
| Standard bucket capacity | 0.6m3 |
| Slewing speed | 13rpm |
| Stick digging force | 50.0KN |
| Bucket digging force | 64.0KN |
| Main Features | |
| Tracked pontoon structure | |
| Big torque travelling device | |
| Big circular arc structure | |
| High capacity of fuel tank | |
| Main Applications | |
| River/Beach earth moving | |
| Swamp works | |
| Dredging applications | |
| Delta works | |
| Waterway deepening | |
| Hydraulic System | |
| Main pump | KAWASAKI |
| Main valve | KAWASAKI |
| Motor | KAWASAKI |
| Hydraulic flow rate | 2x210L/min |
| Hydraulic pressure | 32MPa |
| Travelling System | |
| Travelling speed | 0~4.88km/h |
| Grade ability | 58% |
| Ground pressure | 0.013MPa |
| No. of chains | 300% |
| Dimensions | |
| Overall length | 14500mm |
| Overall width | 6100mm |
| Overall height | 3950mm |
| Ground clearance | 1192mm |
| Length of pontoon | 10200mm |
| Width of pontoon | 1760mm |
| Height of pontoon | 1700mm |
| Optional | |
| Wide bucket | |
| Operating Scope | |
| Stick length | 5200mm |
| A: Max. cutting height | 12190mm |
| B: Max. dumping height | 9800mm |
| C: Max. digging depth | 11600mm |
| D: Max. reach | 15100mm |
