Hydraulic sawdust briquette press machine Sawdust briquette press machine is a die and ram type mechanical press with two flywheels. Each flywheel is driven by belts with motors. Material is continuously fed through a hopper by belt conveyor with its own gearbox and a motor. From feeding chamber, raw material is compressed by ram through taper bore die. Briquettes comes out from cooling track. Total process is continuous and controlled by electric panel. Briquetting press is used for producing high density fuel briquettes
Detailed Images
Hydraulic sawdust briquette press machine Include
1.Screw conveyor
2.Feeding hopper
3.Main press machine
4.Control cabinet
5.Oil cooling equipment
6.Output line
Specifications
Model
| YKB20A
| Length of Raw material
| ≤3 mm
|
Power
| 75KW
| Moisture content of raw material
| From 10% to 13%
|
Capacity
| 1500 kg/h
| Density of the finished product
| 1.1-1.3g/cm3
|
Diamession
| 1800*3800*1700mm
| Shape of the finished product
| cylinder-shaped
|
Weight
| 8000kg
| Heating value
| 3700-5000kcal
|
Raw Material and finshed product
Index Of Briquette
1.Density of briquette :1.1-1.3g/cm3 2.Heating value :3700-5000kcal
3.Sulfur dioxide emissions: 0.38% 4.Carbon dioxide emissions: 0.22%
5.Ash content 3.6%, and the ash could be recycled as agricultural potash, which can realize green recycling.
Our Customers
YUKE products have been a nationwide hot sale ,and exported to various countries and regions aroubd the world such as India ,Malaysia,Vietnam,Philippines,Indonesia,Thailand ,Russia,Africa,South America,Europe,etc.In the industry ,our products have won great popularity and recognition among users.
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to install the machine, training how to use the machine.
*Readily available spare parts.
*Our engineers can provide service overseas.
.
