Product Description
Product Description
XE250E,featuring high efficiency and energy conservation,is mainly used for earth working conditions.The powerful QSB6.7 engine and hydraulic system are matched perfectly,which can guarantee the product reliablity and define high-efficiency operation and fuel economy.With strengthened structural parts,it is applicable for earth working,road construction and municipal engineering,and allow you to get digging and loading operations done easily.
Product Parameters
| SPECIFICATION OF XE250E CRAWLER CRANE |
| Item | Unit | Parameter Value |
| Model | - | XE250E |
| | | |
| Operation Performance Parameter | | |
| Operating weight | kg | 25870 |
| Bucket Capacity | m3 | 1.2 |
| Bucket digging force | kN | 176 |
| Arm digging force | kN | 125 |
| | | |
| Engine Parameter | | |
| Model | - | Cummin QSB6.7 |
| Engine Rated power/speed | kw/rpm | 142/2000 |
| Maximum torque/speed | N.m | 803/1500 |
| Displacement | L | 6.7 |
| | | |
| Dimension Parameter | | |
| Crane Full Dimension(L×W×H) | mm | 3560×1240×2350 |
| Length of boom | mm | 1690 |
| Length of arm | mm | 1100 |
| Track length | mm | 1578 |
| | | |
| Speed Parameter | | |
| Travel speed(H/L) | km/h | 6.0/4.1 |
| Gradeability | ° | 30 |
| Swing speed | r/min | 11.6 |
Detailed Photos
Company Profile
HOKA VEHICLE is located in Shanghai, which is a financial, trade and shipping center in China. All these give our company an obvious superiority in trade, transportation and material flow.
With the professional team, first class design, production experience and market capacity, HOKA VEHICLE has exported and delivered more than 5, 000 units Construction Machinery to countries across Africa Middle East, Southeast Asia and South America.Our main products cover more than 11 series, ranging from Hoisting Machinery, Building Machinery, Earthmoving Machinery, Concrete Machinery,Road Machinery,Logistics Machinery, Trucks, Drilling Machinery, Mining Machinery and all other kinds of Construction Machinery.
