Precision Roll Slitting and Rewinding Machine
Purpose:
This mahcine is applicable for the vertical slitting of various rolling shape materials such as industrial adhesive tape, sheet, aluminum foil, copper foil, compound plastic sheet etc.
Functional characteristics:
The machine is applicable to slit the narrow scope paper. It can automatically meter and count, set length, stop and alarm, while the feeding is controlled through auto rectifiler. So it is characterized by quickness, accurate slitting and ease of operation.
Main Technical Parameters:
Model
| DP-320
|
Cutting Speed ( m/min )
| 80
|
Max Web Width ( mm )
| 320
|
Max Feeding Diameter ( mm )
| 500
|
Max Winding Diameter ( mm )
| 480
|
Minimum slit width(mm)
| 18
|
| Max silit width(mm) | 310 |
Cutting Precision ( mm )
| ±0.30
|
Voltage and Power
| 220v 0.55kw
|
Total Power ( kw )
| 0.75
|
Overall Dimensions ( mm )
| 1300*900*1200
|
Machine Weight ( kg )
| 250
|
>>
