Basic Info.
Milling Cutter Type
All Kinds
Milling Cutter Structure
All Kinds
Automatic Grade
Automatic
Certification
GS, CE, RoHS, ISO 9001
Worktable Size
1000X550mm
X/Y/Z Axis Travel
800/550/550mm
Atc
24 Pieces Arm Type Tool Magazine
Transport Package
Wooden Case
Production Capacity
50 Sets Per Month
Product Description
Vertical CNC Milling Machining Center Machine
Model VMC855
| Item | Unit | VMC855 |
| Table size | mm | 1000*550 |
| T slot | No | 5 |
| Centre distance | mm | 90 |
| T-Width | mm | 18 |
| Max. load of worktable | kg | 600 |
| Longitudinal travel | mm | 800 |
| Cross travel | mm | 550 |
| Vertical travel | mm | 550 |
| spindle nose to table surface | mm | 150-700 |
| Spindle taper | | BT40 |
| Speed Range | rpm | 40-8000 |
| Spindle output torque (Max.) | N.M | 35.8/70 |
| spindle motor power | kw | 11/15 |
| cutting feed X/Y/Z | mm / min | 1-10000 |
| rapid feed X/Y/Z | m / min | 30/30/24 |
| X/Y/Z leadscrew size | mm | 40x16 |
| tool magazine capacity | piece | 24 |
| tool magazine type | | arm type tool magazine |
| Max. tool weight | kg | 8 |
| Max. Tool dia. (full/empty) | | 78/120 |
| Max. Tool length | mm | 300 |
| Tool changing time (tool to tool/cut to cut) | s | 1.55/5 |
| Working accuracy | | |
| positioning accuracy | mm | ±0.005/300 JIS |
| repeat positioning accuracy | mm | ±0.003 JIS |
| overall dimensions(LxWxH) | mm | 2550*3000*2800 |
| Machine weight | kg | 5500 |
Standard configuration:
CNC controller GSK,
Taiwan spindle BT40-150-10000RPM (highest speed 8000rpm),
Taiwan or Germany linear guide ways and ball screws,
Taiwan arm type tool magazine with 24 tools,
spindle blowing chip removal system,
spindle air curtain protection
Japan Nachi bearings,
auto centralized lubrication system,
rigid tapping , two water cooling, one air cooling
electrical hand wheel, working lamp, RS232 interface,
alarm light, DNC online processing , schneider electric , heat exchanger
Optional accessories:
the 4th axis rotary table
chain type chip removal system with flushing
Screw type chip removal system with flushing
Renishaw tool setting probe TS27R
BT40-150 direct connection spindle 10000rpm(highest speed 8000rpm)
oil cooler
BT40-150 12000RPM direct connection spindle with oil cooling (highest speed 10000rpm)
>>
