| US$5,600.00-16,000.00 | 1 set (MOQ) |
| 1 | Cutting graphics | All kinds of plane figure |
| 2 | Cutting speed | 0-4000mm/min |
| 3 | Round tube speed | 0-4000mm/min |
| 4 | Cutting method | Plasma /flame |
| 5 | Cutting area | X:1500mm,Y:2500mm/3000mm |
| 6 | Cutting thickness | Flame :6-200mm, Plasma :1.5-20mm (according to the plasma power supply) |
| 7 | Thickness of circular tube | Flame :6-80mm,plasma1-20mm (according to the plasma power supply) |
| 8 | Max tube diameter | 0-250mm(can be customized ) |
| 9 | Cutting length | According to different machine size |
| 10 | cutting precision | ±0.5mm |
| 11 | NC programming | Support AUTOCAD/TYPE3/CAXA/SOLIDWORKS.. |
| 12 | File transfer | U disk |
| 13 | Power supply voltage | 220V 50HZ /plasma:380V |
| 14 | Work environment temperature | Temperature:-10ºCto +60ºC, Relative humidity:0-95%No condensation |
| HUAYUAN LGK:(A) | 63 | 100 | 120 | 160 | 200 | 300 |
| Cutting Thickness:(mm) | 8 | 15 | 20 | 30 | 35 | 40 |
| Hypertherm:(A) | 45 | 65 | 85 | 105 | 125 | 200 |
| Cutting Thickness:(mm) | 8 | 10 | 20 | 18 | 25 | 30 |
