| General | |
| Frequency Range | UHF: 400-480MHz |
| Channel Capacity | 16 |
| Channel Spacing | 25KHz/12.5KHz |
| Voltage | DC 3.7V (±20%) |
| Frequency Stability | ≤±2.5 ppm |
| Antenna Impedance | 50Ω |
| Battery Capacity | 2000mAh |
| Working Temperature | -20ºC ~ +60ºC |
| Dimensions | 55(L)*35(W)*122(H)mm |
| Weight | 198g(battery included) |
| Transmitter | |
| Output Power | <5w |
| Modulation | 11KΦF3E/16KΦF3E |
| Rated Audio Distortion | ≤5% |
| Adjacent Power | 60 dB |
| Modulation Limitation | ≤5KHz(width)/2.5KHz(narrow) |
| Receiver | |
| Sensitivity | ≤-123dBm (12 dB SINAD) |
| Adjacent Selectivity | ≥60dB(width)/ 55dB (narrow) |
| Intermodulation Rejection | ≤60 dB (width/ 55 dB (narrow) |
| Spurious Suppression | ≥60dB(width)/ 55dB (narrow) |
| SNR | ≥40B(width)/ 35dB (narrow) |
| Rated audio output power | 0.5W |
| Rated audio distortion | ≤5% |
