Basic Info.
Model NO.
GF2 /GF1-10kw to 500kw
Type
Micro-Computer Control Automatic Diesel Generator
Installation Method
Fixed
Cooling Method
Water Cooling
Output Type
AC Three Phase
Conditions of Use
Land Use
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
Static Exciter
Weifang Generator
GF1/GF2 - W10kw to GF1/GF2-W120kw
Lovol Engine Generator
GF1/GF2 -L20kw to GF1/GF2-L120kw
Weichai Engine Generator
GF1/GF2-W16kw to GF1/GF2-W55okw
Yuchai Engine Geneator
GF1/GF2-Yc20kw to GF1/GF2-Yc800kw
Foton Engine Generator
GF1/GF2-Is20kw Togf1/GF2-Is25kw
Transport Package
by steel frame with plywood case
Specification
30kw to 500kw
Production Capacity
1000pcs/year
Product Description
diesel generator
GF2 10KW-500KW Silent Open Diesel Generator with CE
Different kinds of alternator
Competitive price
Good after sales service
Reliable quality, high precision, larger power
Generator set
Engine power range from 20kw to 500kw
Alternator: BRUSHLESS
Speed 1500rpm/1800rpm
Frquency: 50Hz/60Hz rated voltage: 230v/400v
Rated current 50A-900A
Color: Yellow, orange green, white
Output type: AC THREE PHASE
| MODEL | GF2-C100kw/125KVA |
| Powered by WEICHAI Engine |
| Prime Power (50HZZ) | 100KW/125KVA |
| Standby Power (50HZ) | 112kw/140KVA |
| Power Factor | 0.8 Lagging |
| Phase Wires | 3-phases 4-Wires |
| Start Model | Electric |
| Protection | Low oil-pressure, High water temperature,
Over-speed, Over-current |
| Engine Model | 6BTA5.9-G2 |
| Cylinders | 6 |
| Cylinder Arrangement | L |
| Bore x Stroke(mm) | 102X 120 |
| Compression Ratio | 17.5: 1 |
| Speed | 1500rpm |
| Cooling Method | Water - cooled |
| Starting Method | 24V DC electrical start |
| Full Load Diesel Consumption (L/H) | 25 |
| Engine Displacement (L) | 5.9 |
| Inspiration (L) | Natural |
| Lube Volume (L) | 14.3 |
| Coolant Volume (L) | 25 |
| Noise (Db) | ≤ 80 |
| Alternator Model | BRUSHLESS 274E |
| Alternator Power | 112KW/140KVA |
| Voltage | 230/400 V |
| Protection | IP23 |
| Voltage Regulation | ± 4% |
| Insulation Class | H |
| Voltage Control | AVR |
| Net Weigh (KGS) | 1400 |
| Dimensions (L x W x H) mm | 2900*1230*1700 |
| Optional | ATS (auto transfer switch) |
| | BatteryCharger |
| | Base fuel tank (for open type) |
>>
