General Technical Characteristics
Low losses, high stability, high insulation resistance
Small size, long life
Coated with flame-retardant epoxy resin.
Typical Applications
Used in peak value current and high repetition rates circuit.
For points voltage protection, decoupling circuit, laser inspired, switching circuit, welding equipment, AC current limiting, dc energy storage, high frequency coupling, communication, DC filtering and so on.
Electrical Characteristics
Rated Voltage : 1KVDC ~ 30KVDC
Capacitance Range : 10pF ~ 47000pF
Capacitance Tolerance : ±5% (J), ±10%(K), ±20%(M)
Test Voltage : 1KV≤UR≤2KV, 2UR for 1 min.
2KV
8KVCapacitance
| TOL.
%
| 2KV
| Ceramic
|
D
| T
| F
| d
|
10pF
| 10
| 8
| 4
| 5
| 0.6
| UJ
|
15pF
| 10
| 8
| 4
| 5
| 0.6
| UJ
|
22pF
| 10
| 8
| 4
| 5
| 0.6
| SL
|
27pF
| 10
| 8
| 4
| 5
| 0.6
| SL
|
33pF
| 10
| 8
| 4
| 5
| 0.6
| SL
|
47pF
| 10
| 8
| 4
| 5
| 0.6
| SL
|
56pF
| 10
| 8
| 4
| 5
| 0.6
| SL
|
68pF
| 10
| 8
| 4
| 5
| 0.6
| SL
|
100pF
| 10
| 8
| 4
| 5
| 0.6
| SL
|
150pF
| 10
| 12
| 4
| 9.5
| 0.6
| SL
|
220pF
| 10
| 12
| 4
| 9.5
| 0.6
| SL
|
330pF
| 10
| 14
| 4
| 9.5
| 0.6
| SL
|
470pF
| 10
| 16
| 4
| 9.5
| 0.6
| SL
|
560pF
| 10
| 18
| 4
| 9.5
| 0.6
| SL
|
100pF
| 10
| 8
| 4
| 5
| 0.6
| X5F
|
Capacitance
| TOL.
%
| 20KV
| Ceramic
|
D
| T
| F
| d
|
100pF
| 10
| 8
| 8
| 9.5
| 0.65
| N4700
|
150pF
| 10
| 10
| 8
| 9.5
| 0.65
| N4700
|
220pF
| 10
| 11
| 8
| 9.5
| 0.65
| N4700
|
330pF
| 10
| 9
| 7.5
| 9.5
| 0.65
| Y5T
|
500pF
| 10
| 14
| 9
| 12.5
| 0.8
| Y5T
|
1000pF
| 10
| 21
| 8
| 12.5
| 0.8
| N4700
|
1000pF
| 10
| 14
| 7.5
| 12.5
| 0.8
| Y5T
|
1000pF
| 20
| 10
| 7.5
| 9.5
| 0.65
| Y5V
|
2200pF
| 20
| 21
| 8
| 12.5
| 0.8
| Y5T
|
2200pF
| 20
| 17
| 9
| 12.5
| 0.8
| Y5U
|
3300pF
| 20
| 27
| 9
| 20
| 1.2
| Y5T
|
3300pF
| 20
| 21
| 9
| 12.5
| 0.8
| Y5U
|
4700pF
| 20
| 32
| 10
| 20
| 1.2
| Y5T
|
4700pF
| 20
| 27
| 11
| 20
| 1.2
| Y5U
|
4700pF
| 20
| 21
| 11
| 17.5
| 0.8
| Y5V
|
10000pF
| 20
| 43
| 11
| 20
| 1.2
| Y5T
|
10000pF
| 20
| 26
| 12
| 20
| 1.2
| Y5V
|
Capacitance
| TOL.
%
| 30KV
| Ceramic
|
D
| T
| F
| d
|
100pF
| 10
| 10
| 9
| 12.5
| 0.8
| N4700
|
150pF
| 10
| 12
| 9
| 12.5
| 0.8
| N4700
|
220pF
| 10
| 12
| 9
| 12.5
| 0.8
| N4700
|
501pF
| 10
| 19
| 11
| 17.5
| 0.8
| N4700
|
1000pF
| 20
| 19
| 11
| 17.5
| 0.8
| Y5T
|
2200pF
| 20
| 27
| 12
| 20
| 1.2
| Y5T
|
2200pF
| 20
| 24
| 14
| 20
| 1.2
| Y5U
|
2200pF
| 20
| 19
| 14
| 17.5
| 0.8
| Y5V
|
3300pF
| 20
| 32
| 12
| 20
| 1.2
| Y5T
|
5000pF
| 20
| 40
| 13
| 20
| 1.2
| Y5T
|
6000pF
| 20
| 43
| 13
| 20
| 1.2
| Y5T
|
10000pF
| 20
| 40
| 13
| 20
| 1.2
| Y5U
|
10000pF
| 20
| 32
| 13
| 20
| 1.2
| Y5V
|
Remark: Customization for special specification and requirement is available.
