Used Concrete Pump Trailer Pumping Concrete for Sale

US$4,500.00-8,000.00 1 Set (MOQ)

Basic Info.

Model NO.

LMP7/35

Machining Process

Hydraulic

Productivity

7.5m3/H

Certification

ISO9001: 2000, CE

Condition

New

Color

Yellow

Pump Work Pressure

35 Bar

Cylinder Diameter

120mm

Cylinder Stroke

360mm

Main Motor Power

15kw

Max. Vertical Conveying Distance

30m

Max. Horizontal Conveying Distance

90m

Net Weight

750kg

Transport Package

Standard Export Packing or as Your Request

Specification

1950*700*1130mm

Trademark

Leadcrete

Origin

China

HS Code

8413400000

Production Capacity

1000 Set/Year

Product Description

Used concrete pump trailer pumping concrete for sale
LMP7/35 is a concrete & grout pump designed for masonry grouting and shotcrete applications. It features up to 7.5 cubic meters per hour production output. This product is a new, multi-purpose, multi-purpose industrial pump developed by absorbing advanced technology from abroad. Typical applications include: masonry block filling, wall grouting, hoisting mortar for masonry wall construction; concrete sidewalk and patio slab pumping; low-volume shotcrete.
Technical data sheet:

Name	Mini Masonry concrete pump
Model	LMP7/35
Output	7.5m3/h
Pumping Pressure	35bar
Max. Aggregate Size	15mm
Cylinder diameter	Ø120mm
Cylinder Stroke	360mm
Conveying Hose Inner Diameter	Ø80mm
Main Motor Power	15Kw
Max. Vertical Conveying Distance	30m
Max. Horizontal Conveying Distance	90m
Overall Dimension	19507001130mm
Weight	750kg
Note: the machine can be equipped with electric walking device according to customer demands.

Detailed images:


The electric switch	Polyether material piston


The foot brake	Self-Propelled Electric walking device

Application:
Packaging & Shipping:
Company Information:
