Xw6 Worm Gearbox for Ball Valve

Product Description

Introduction
XW series Part-turn Worm Gearbox is precison device(rotary) with high quality and safety,intended to reduce the speed and increase thetorque. It is easy to process axis hole and key groove because of the removable sleeve.
Characters
1.Totally enclosed gearing
2.Grease filled for longer life
3.Comprehensive gear ratios for different
applications
4.Removable output sleeve
5.Optional travelling sleeve
6.Adjustable stopper (± 5°)
7.Optional flange to suit for different type of valve
Application
XW series part-turn worm gearboxes are used for manual and electric (electric actuator) applications of ball valves,butterfly valves, plug valves and dampers.
Operating Environment
XW series part-turn worm gearboxes are with good mechnical quality and steady operating performance which apply to deal with variety climate and temperature. We strive to develop XW series worm gear operator to meet higher demands.
Enclosure: IP67
Working Temperature: Form-20ºCto120ºC(-4ºFto248ºF)
Painting: Silver grey (customization)
Connect With Valve
The flange connecting to valve is according to ENISO5210 or DIN3210 (Customization)

Model	Electric Output Torque N·m	Ratio	Electric Input Torque N·m	Input Flange ISO5210-2001	Standard Base Output Flange	Thickened Base Output Flange	Maximum Stem Diameter mm	Input Shaft Diametermm	APPROX. Weight kg
XW3	800	58	46	F10/F14	F12	F10/F12/F14	43	15	15
XW4	1700	68	83	F10/F14	F14	F12/F14/F16	52	20	23
XW5	3000	67	149	F10/F14/F16	F16	F14/F16/F25	76	20	50
XW6	7000	69	338	F14/F16	F25	F16/F25/F30	87	30	83
XW7	16000	60	889	F14/F16/F25	F25/F30	F35	120	30	144
XW8	28000	60	1556	F14/F16/F25	F25/F30/F35	F40	153	35	254
XW9	40000	60	2222	F14/F16/F25	F30/F35	F40/F48	170	40	327
XW10	65000	60	3611	F16/F25/F30	F35/F40	F48	190	50	493
