Taiwan Fanuc CNC Milling Machine Vmc1370 Heavy Duty CNC Vertical Machining Center

Product Description

Vertical machining center EV1370
EV series rapid parts processing center is applied to:
Auto parts, aluminum parts, die-casting parts, 5G communications and other precision parts processing.
EV series technical highlights
1. The z-axis adopts the design of no weight to increase the direct drive of the z-axis motor and makethe high-speed feed or drill pick control accurate.
2. Standard BT40 direct spindle driven by coupling, no belt noise, low vibration, more suitable for highspeed and high precision processing (optional).
3. The triaxial motor seat and the casting are cast simultaneously to increase the rigidityand precision of feed system.
4. The one-piece bearing, block is machined with unique precision bearing sleeve design to ensure thethree-point concentricity of screw assembly and long precision maintenance.
5. The base, integrated with a gradient chassis, provides the most stable load-bearingcapacity,with standard side flush, not easy to chip.
EV series Parameter (Specification)

Journey	Unit	EV-600	EV-800	EV-1060	EV-1160	EV-1370
X Y Z Triaxial Travel	mm	600/400/450	800/500/550	1000/600/600	1100/600/600	1300/700/700
The Distance From The Nose Of The Spindle To The Work Table	mm	135-585	120-670	150-750	120-720	120-820
Distance Between Center Of Spindle And Guide Surface Of Z Axis	mm	488	550	655	660	770
Axial
X Y Z Rapid Movement Speed	mm/min	48000	48000	36000	36000	30000
The Workbench
Table Size	mm	700X400	1000X500	1100X600	1200X600	1400X700
Maximum Working Load	kg	350	450	500	600	1000
T Groove Width X Groove Number X Spacing	-	14*3*125	18*5*80	18*5*100	18*5*100	18*5*125
Spindle
Spindle Speed	rpm	12000	12000	12000	12000	10000
The Spindle Diameter	mm	120	140	150	150	150
Main Shaft Taper	-	BT40	BT40	BT40	BT40	BT40
Spindle Power (Horse-Power)	KW	7.5	11	15	15	15
Knife Library
Item Number	T	24	24	24	24	24
Maximum Prop Weight	kg	7	7	7	7	7
Knives You Exchange Time (Knife To Knife)	S	1.8	2	2	2	2
Positionai Accuracy	mm	±0.005	±0.005	±0.005	±0.005	±0.005
Repeated Positioning Accuracy	mm	±0.003	±0.003	±0.003	±0.003	±0.003
The General Information
Machine Weight	kg	4500	5500	6300	7300	8500
Maximum Mechanical Height	mm	2400	2400	2400	2700	3000
Machine Cover Size (Length X Width)	mm	1800X2750	2500X2150	2700X2300	2900X2400	3300X2700
Power Demand	kva	15	15	15	15	15

EV series feature of Spindle
1. Roller track ensures strength while increasing movement speed.
2. Saddle adopts two track and six slide block design.
3. The ultra wide base of integrated forming has high rigidity and stability.
Technical and After-sales Service
1. English Technical files provided.
2. Machine tested before the delivery.
3. Technical support online service provided(Provide site test).
4. Consumable parts at reasonable price when replaced.

---
