| US$1.00-2.00 | 1 Piece (MOQ) |
| PET STYLE SPECIFICATION | UE/410 | ||||
| SCREW TYPE | A | B | C | D | |
| Injection Unit | |||||
| Screw diameter | mm | 70 | 75 | 80 | 85 |
| Screw L/D ratio | L/D | 25 | 25 | 25 | 25 |
| Shot volume(theoretical) | CM3 | 1501 | 1723 | 1960 | 2213 |
| Injection weight(PET) | g | 1871 | 2148 | 2444 | 2759 |
| Injection rate | g/s | 459 | 527 | 600 | 677 |
| Injection pressure | MPA | 199 | 173 | 152 | 135 |
| Screw speed | rpm | 130 | |||
| Clamping Unit | |||||
| Clamping force | KN | 4100 | |||
| Open stroke | mm | 715(720) | |||
| Space between tie-bars(W*H) | mm | 730*730 | |||
| Max mould height | mm | 780 | |||
| Min mould height | mm | 250 | |||
| Ejector stroke | mm | 180 | |||
| Ejector force | KN | 90 | |||
| Others | |||||
| Max pump pressure | MPA | 16 | |||
| Pump Motor power | KW | 45.2 | |||
| Heating power | KW | 29.3 | |||
| Numbers of heating area | Segment | 5+1 | |||
| Machine dimension(L*W*H) | M | 7.65*2.05*2.6 | |||
| Oil tank cubage | L | 690 | |||
| Machine weight | TON | 16 | |||
| Name | Brand |
| Computer | KEBA(AUSTRIA) or EST |
| Servo Drive | INOVANCE(CHINA) |
| Servo Pump | SUNNY(USA) / SUMITOMO(JAPAN) |
| Servo Motor | PHASE(ITALY) |
| Electro-hydraulic Proportion valve | HNC (Taiwan) |
| Stroke transducer | NOVO or Miran(GERMANY)/GERFRAN(ITALY) |
| Breaker | Schneider (FRANCEN)/Siemens(GERMANY) |
| Contacts | Schneider (FRANCEN)/Siemens(GERMANY) |
| Switch | Schneider (FRANCEN)/Siemens(GERMANY) |
| Hydraulic Direction Valve | Vickers (USA) or Rexroth (GERMANY) |
| Plasticing Motor | DINAMIC(ITALY) or STF(ENGLAND) |
| Hydraulic Hose | MANULI(ITALY)/CONTINENTAI(GERMANY) |
| Plasticing speed sensor | OMRON |
| Sealing ring | HALITE or TREIIEBORG(UK or GERMANY) |
