Electric Surface Grinding Machine MD618A, Metal Precision Surface Grinder

Product Description

Product description:
Feature :
1. The machine has reasonable structure, good rigidity, beautiful appearance, convenient operation.
2. The transverse motion of the working table can be used to realize the mechanical transmission and the manual transmission.
3. The longitudinal movement of the working table can achieve mechanical drive and manual drive.
4. Can grinding a variety of flat and complex shape, suitable for grinding without motorized feed, according to the user needs to be equipped with permanent magnetic or electromagnetic chuck.
Technical parameter :
Specification:

Technical Parameters	Units	MD618A
Max.workpiece to be Ground	Mm	500×190×335
Max. Grinding Length	Mm	500
Max. Grinding Width	Mm	190
Distance From Table To Spindle	Mm	335
Slide way		V-type rail with Steel-ball
Table Size (L×W)	Mm	460×180
Number of T -Slot	Mm	14×1
Cross Feed On Handwheel	Mm	0.02/Gra 2.5/rev
Vertical Feed On Handwheel	Mm	0.01/Gra 1.25/rev
Table longitudinal (left and right) speed	m/min	3-20
Wheel Size	Mm	180×13×31.75
Spindle Speeds	rpm	2850
Spindle Motor	kw	1.1
Coolant Pump	kw	0.04
Machine Size	mm	1000x1060x1590
Packing Size	mm	1240x1080x1680
Gross,Net/weight	kg	750/650

Standard accessories :
Wheel flange
Balancing arbor
Wheel exactor
Coolant tank
Working lamp
Too box and tools
Balance stand
Leveling wedge and bolt
Wheel dresser stand
Optional accessories :
Electro magnetic chuck
Balancing stand
Cooling and dust collector
Parallel wheel dresser
Dust collector
2 axis DRO
Company information:
FAQ
Q: Are you a trading company or a physical factory?
A: We are a specialized physical factory for more than 10 years. Our machines also gained CE certificate, ISO9001 and EAC certificate.
Q: What's your main products of your company?
A : We specialized in Vertical Machining Center, CNC Lathe, Milling Machines, Lathes, Drilling Machines, Saws, Shapers and so on.

Q: Can you provide customized machine?
A: Yes, we provide customized service for customers to meet different requirements.


Q: Can we visit your factory?
A: Sure, we warmly welcome you to visit our factory at any time. The more you know about us, the more you will trust us! So you can rest assured on our quality machines and our best service.
Q: What's the Payment Terms ?
A : T/T ,30% deposit when order ,70% balance payment before shipment ; Irrevocable LC at sight.
Q: What is your trade terms?
A: FOB, CIF ,DDP and CFR all acceptable.

---
