Product Details
Product Description
Product Description
Overview
The HBN Q8D Handheld Smart Laser Marking Machine is a portable, battery-powered, and fully autonomous marking solution. Designed for versatility and ease of use, it is ideal for marking on large, cumbersome, or difficult-to-move workpieces. Its lightweight design and powerful performance make it a reliable tool for various industrial applications.
Key Features
Portable & Cordless Design:
Powered by a robust 24V rechargeable lithium battery, providing up to 6.8 hours of continuous operation under normal use.
Eliminates cable drag and avoids sudden power failures, ensuring uninterrupted workflow.
High Performance:
Laser Output Power: 18.5W with a wavelength of 1064nm.
Marking Range: 100mm x 100mm, with an engraving depth of ≤1mm (adjustable based on power and time).
High-Speed Marking: Engraving speed of up to 10,500mm/s for efficient operations.
Precision & Reliability:
Beam Quality (M²): ≤1.4, ensuring sharp and precise markings.
Minimal Line Width/Character Height: 0.1mm for fine details.
Pulse Frequency: 27–40 kHz for consistent performance.
User-Friendly Operation:
Ergonomic grip for comfortable handling (marking head weighs only 2.46kg).
Supports USB interface and Linux operating system for seamless connectivity.
Compatible with various file formats, including text, patterns, QR codes, barcodes, serial numbers, and graphics.
Durable & Compact:
Includes a dedicated storage box for easy transport and protection.
Whole machine weight: 2.8kg (compact and lightweight for handheld use).
Built-in Cooling System:
Equipped with an air cooling mechanism to maintain optimal performance during extended use.
Technical Specifications
CategorySpecifications
| Model | Q8D-20 |
|
|
| Laser Parameters | Output Power: 18.5W | Wavelength: 1064nm | Power Stability: | Optical Properties | Marking Range: 100x100mm | Engraving Speed: ≤10,500mm/s | Resolution: ≤0.005mm |
| Battery & Power | Battery Life: 6.8 hours | Input Voltage: 100-240V AC, 50/60Hz |
|
| Software Support | Text, Patterns, QR Codes, Barcodes, Serial Numbers, Graphics (supports 1024 fonts) |
|
|
| Dimensions & Weight | Control Box: 255×150×80mm | Marking Head: 250×210×160mm | Total Weight: 2.8kg |
Applications
The HBN Q8D is widely used in industries requiring precise and portable marking solutions, including:
Automotive Manufacturing
Aerospace Industry
Metal Processing
Construction & Machinery
Household Appliances
Energy Sector
>>
