Product Details
Product Description
Product Description
Technical Features:
· Digital closed-loop mode, bias stability: 0.015～0.05º/h,
10s smoothing
· Volume Φ98mm×35mm, Weight: ≤518g
Typical Application:
· Precise north-seeking, high-precision inertial navigation system, vehicle positioning, and orientation
Performance Indicators:
Project
| Unit
| FOG900A
| FOG900B
| FOG900C
| FOG900D
|
Measuring Range
| º/s
| -500~+500
| -500~+500
| -500~+500
| -500~+500
|
Bias Stability
| º/h，10s
| ≤0.015
| ≤0.02
| ≤0.03
| ≤0.05
|
º/h，100s
| ≤0.007
| ≤0.008
| ≤0.01
| ≤0.015
|
Bias Repeatability
| º/h
| ≤0.008
| ≤0.009
| ≤0.01
| ≤0.015
|
Random Walk Coefficient
| º/√h
| ≤0.0015
| ≤0.002
| ≤0.003
| ≤0.005
|
Scale Factor Nonlinearity
| ppm
| ≤20
| ≤30
| ≤40
| ≤50
|
Scale Factor Repeatability
| ppm
| ≤20
| ≤30
| ≤40
| ≤50
|
Scale Factor Asymmetry
| ppm
| ≤20
| ≤30
| ≤40
| ≤50
|
Start Time
| s
| ≤1
|
Bandwidth
| Hz
| ＞200
|
Power Supply
| V
| -5,+5
|
Power
| W
| ≤6
|
Operating Temperature
| ℃
| -40~+65
|
Storage Temperature
| ℃
| -55~+85
|
Vibration
| Hz, g2/Hz
| 20～500,0.06
|
Impact Resistance
| g， ms
| 30,11
|
Data Refresh Rate
| Hz
| 200~2000
|
Baud Rate
| bps
| 115200~921600
|
Output Mode
| /
| Broadcast (default)/Triggered (Customized)
|
Interface Level
| /
| RS-422
|
Connector
| /
| J30J-15TJL
|
Boundary Dimension
| mm
| Φ98×35
|
>>
