Strong Cutting Metal Parts Milling Machine Fresadora Precision Metal Milling Machine Tool

Product Description

Strong cutting and high efficiency production capacity
√ Spindle tolerance: 0.005mm.
√ Suitable for plastics, metal mold processing and other strong cutting parts.
√ Exclusive spindle assembly technology with high precision and cutting efficiency.
1. WORKTABLE
Crafted with meticulous attention to detail, featuring ultra-audio quenching, precision grinding, and expert scraping guides. Enhance versatility with an optional rotary table.
2. TURRET MILLING HEAD
Our versatile turret milling head swivels 45° forward-backward and rotates 90° left-right, enabling seamless milling at diverse and challenging angles.
3. SPINDLE
Equipped with a high precision R8/NT30/NT40 spindle, boasting a spindle runout of just 0.003mm, for unmatched accuracy in your machining tasks.
4. X/Y/Z AUTO FEED
Achieve remarkable efficiency with the X/Y axis auto feed and Z axis electric lifting, revolutionizing your machining process by streamlining operations.
5. DRO
Customize your setup with an optional 2-axis or 3-axis DRO to meet your specific requirements, significantly enhancing operational accuracy and precision.
Strong Cutting Metal Parts Milling Machine Fresadora Precision Metal Milling Machine Tool

Model				4SB
Table size			mm	1270*254*90
Travel		X axis	mm	900
		Y axis	mm	370
		Z axis	mm	360
Travel of spindle quill			mm	127
Maximum distance from spindle nose to table			mm	400
Spindle	Rotation speed (Step speed milling head)	50HZ	rpm	66-4540
		60HZ	rpm	80-5440
	Rotation speed (Variable speed milling head)	50HZ	rpm	40-3125
		60HZ	rpm	50-3750
	Rotation speed (Inverter speed milling head)	50HZ	rpm	0-4200
		60HZ	rpm	0-4200
	Taper			R8/NT30
	Rated power		HP	3HP
Tilt Angle			Forward and backward	±45°
			Left and Right	±90°
Dimension			mm	1500*1700*2150
Weight			kg	1500

As a leading force in the industry, Shenzhen Joint Machinery Co., Ltd. proudly stands as a top-tier professional manufacturer and exporter of CNC lathe machines, CNC deep hole drilling machines, and Swiss-type automatic lathes. Our extensive range also includes innovative milling and grinding machines. Our unwavering dedication to delivering superior machines and unmatched service has earned us a global reputation for excellence. By integrating state-of-the-art technologies from Taiwan and Germany, our production processes consistently achieve the pinnacle of quality and reliability. Renowned for their exceptional performance in precision, stability, and reliability, our machines are crafted to meet the diverse and intricate demands of complex machining tasks. Our esteemed products have achieved international recognition, reaching markets across Asia, Europe, South America, North America, and beyond. We are committed to cultivating enduring partnerships with clients worldwide, continuously creating significant business value together.

---
