10kw 20kw 30kw off-Grid Solar Inverter Pure Sine Wave Inverter

US$1,463.00

1-9 Pieces

US$1,405.00

10+ Pieces

Basic Info.

Model NO.

NB48-10KDZ

Nature of Source Flow

Passive inverter

Phase

Single

Output Power

>1000W

Certification

CE, ISO9001

Type

DC/AC Inverters

Power Source

Solar Power, Wind Power

Circuit Topologies

Full-Bridge Type

Nature of Wave String

Sine Wave Inverter

Product Name

30kw off Grid Sine Wave Single Phase Inverter

Application

Solar Power System Home

Output Waveform

Pure Sine Wave Output

Display

Efficiency

93%-97% ( High Efficiency )

Output Rated Current

272A / 250A / 136 a /125A

Output Voltage Accuracy

110 VAC / 120 VAC / 220 VAC / 240 VAC± 1%

Output Frequency Accuracy

50Hz / 60Hz ±0.05%

Inverter Efficiency

94%

Transport Package

Wooden Case

Specification

800*600*2260mm 360kg

Trademark

Deming

Origin

China Jinan

HS Code

8504403090

Production Capacity

5000/Year

Product Description

Product Description
Detailed Photos
Product Parameters
10KW off grid single phase inverter technical parameters

Type		NB48-10KDZ	NB96-10KDZ	NB120-10KDZ	NB240-10KDZ
DC input	Input rated voltage	48 VDC	96 VDC	120 VDC	240 VDC
	Input rated current	231 A	116 A	93 A	46 A
	Input DC voltage range	40-62 VDC	80-124 VDC	100-155 VDC	200-310 VDC
AC input	Allow input voltage range	110 VAC / 120 VAC / 220 VAC / 240 VAC ± 15% VAC
	Input rated current	91A / 104A / 45.5 A / 42A
	Bypass transfer time	≤40 ms(Can be customized ≤4ms version)
AC output	Output rated power	10KW
	Output rated voltage and frequency	110 VAC / 120 VAC / 220 VAC / 240 VAC,50Hz / 60Hz
	Output rated current	91A / 104A / 45.5 A /42A
	Output voltage accuracy	110 VAC / 120 VAC / 220 VAC / 240 VAC± 1%
	Output frequency accuracy	50Hz / 60Hz ± 0.05%
	Waveform distortion (THD).	≤3% (Linear load)
	Dynamic response time (Load 0←→100%)	2ms
	Power factor (PF)	1
	Overload capacity	120%,5 minutes;200%,3 seconds
	Crest factor (CF)	3:1
	Inverter efficiency	94%
Working Environment	Dielectric strength	1500VAC,1minute
	Noise (1m)	≤50dB
	Ambient temperature	-20ºC~+60ºC
	Humidity	0~90%, No condensation
	Altitude	<6000m Higher than 2000m rated power should be reduced
Production function	Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection
Equipped with isolated transformer		Yes
Pure Sine Wave		Yes
AC Charger		Available, optional
Solar Battery Charger		Available, optional
Dry Contact		Available. optional
Size	5504801200mm
Weight	130kg

15KW off grid single phase inverter technical parameters

Type		NB48-15KDZ	NB96-15KDZ	NB120-15KDZ	NB240-15KDZ
DC input	Input rated voltage	48 VDC	96 VDC	120 VDC	240 VDC
	Input rated current	347 A	174 A	139 A	69 A
	Input DC voltage range	40-62 VDC	80-124 VDC	100-155 VDC	200-310 VDC
AC input (AC Bypass)	Allow input voltage range	110 VAC / 120 VAC / 220 VAC / 240 VAC ± 15% VAC
	Input rated current	136A / 125A / 68A / 62.5A
	Bypass transfer time	≤100 ms(Can be customized ≤4ms version)
AC output	Output rated power	15KW
	Output rated voltage and frequency	110 VAC / 120 VAC / 220 VAC / 240 VAC,50Hz / 60Hz
	Output rated current	136A / 125A / 68A / 62.5A
	Output voltage accuracy	110 VAC / 120 VAC / 220 VAC / 240 VAC± 1%
	Output frequency accuracy	50Hz / 60Hz ± 0.05%
	Waveform distortion (THD).	≤3% (Linear load)
	Dynamic response time (Load 0←→100%)	2ms
	Power factor (PF)	1
	Overload capacity	120%,5 minutes;200%,3 seconds
	Crest factor (CF)	3:1
	Inverter efficiency	94%
Working Environment	Dielectric strength	1500VAC,1 minute
	Noise (1m)	≤50dB
	Ambient temperature	-20ºC~+60ºC
	Humidity	0~90%, No condensation
	Altitude	<6000m (Higher than 2000m rated power should be reduced)
Production function	Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection
Equipped with isolated transformer		Yes
Pure Sine Wave		Yes
AC Charger		Available, optional
Solar Battery Charger		Available, optional
Dry Contact		Available. optional
Size	5504801200mm
Weight	200kg

20KW off grid single phase inverter technical parameters

Type		NB48-20KDZ	NB96-20KDZ	NB120-20KDZ	NB240-20KDZ
DC input	Input rated voltage	48 VDC	96 VDC	120 VDC	240 VDC
	Input rated current	463 A	231 A	185 A	93 A
	Input DC voltage range	40-62 VDC	80-124 VDC	100-155 VDC	200-310 VDC
AC input (AC Bypass)	Allow input voltage range	110 VAC /120 VAC /220 VAC /240 VAC ± 15% VAC
	Input rated current	182A / 167A / 91 A / 83A
	Bypass transfer time	≤100 ms(Can be customized ≤4ms version)
AC output	Output rated power	20KW
	Output rated voltage and frequency	110 VAC / 120 VAC / 220 VAC / 240 VAC ,50Hz / 60Hz
	Output rated current	182A / 167A / 91 A / 83A
	Output voltage accuracy	110 VAC / 120 VAC / 220 VAC / 240 VAC±1%
	Output frequency accuracy	50Hz / 60Hz ± 0.05%
	Waveform distortion (THD).	≤3% (Linear load)
	Dynamic response time (Load 0←→100%)	2ms
	Power factor (PF)	1
	Overload capacity	120%,5 minutes;200%,3 seconds
	Crest factor (CF)	3:1
	Inverter efficiency	90%
Working Environment	Dielectric strength	1500VAC,1minute
	Noise (1m)	≤50dB
	Ambient temperature	-20ºC~+60ºC
	Humidity	0~90%, No condensation
	Altitude	<6000m Higher than 2000m rated power should be reduced
Production function	Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection
Equipped with isolated transformer		Yes
Pure Sine Wave		Yes
AC Charger		Available, optional
Solar Battery Charger		Available, optional
Dry Contact		Available. optional
Size	6109501300mm
Weight	210kg

30KW off grid single phase inverter technical parameters

Type		NB120-30KDZ	NB240-30KDZ	NB380-30KDZ
DC input	Input rated voltage	120 VDC	240 VDC	380 VDC
	Input rated current	278 A	139 A	88 A
	Input DC voltage range	100-155 VDC	200-310 VDC	320-496VDC
AC input (AC Bypass)	Allow input voltage range	110 VAC / 120 VAC / 220 VAC / 240 VAC ± 15% VAC
	Input rated current	272A / 250A / 136 A /125A
	Bypass transfer time	≤100 ms(Can be customized ≤4ms version)
AC output	Output rated power	30KW
	Output rated voltage and frequency	110 VAC / 120 VAC / 220 VAC / 240 VAC,50Hz / 60Hz
	Output rated current	272A / 250A / 136 A /125A
	Output voltage accuracy	110 VAC / 120 VAC / 220 VAC / 240 VAC± 1%
	Output frequency accuracy	50Hz / 60Hz ±0.05%
	Waveform distortion (THD).	≤3% (Linear load)
	Dynamic response time (Load 0←→100%)	2ms
	Power factor (PF)	1
	Overload capacity	120%,5 minutes;200%,3 seconds
	Crest factor (CF)	3:1
	Inverter efficiency	94%
Working Environment	Dielectric strength	1500VAC,1minute
	Noise (1m)	≤50dB
	Ambient temperature	-20ºC~+60ºC
	Humidity	0~90%, No condensation
	Altitude	<6000m Higher than 2000m rated power should be reduced
Production function	Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection
Equipped with isolated transformer		Yes
Pure Sine Wave		Yes
AC Charger		Available, optional
Solar Battery Charger		Available, optional
Dry Contact		Available. Optional
Size(mm)	8006002260mm
Weight(kg)	360kg
