Introductions of Moresuperhard’s 1A1R metal CBN grinding wheelCBN grinding wheel grinding is a new kind of application fields of superhard materials, to improve the level of machinery manufacture finishing has a strong role, for the mechanical processing industry to the high efficiency, high precision, high automation and provides a sufficient condition for the development of high-quality products, CBN grinding wheel, more and more applied in bearing manufacturing industry, automobile, aviation and tools.
Model
| D(mm)
| T(mm)
| U(mm)
| H(mm)
| X(mm)
|
1A1R
| 4” /100
| 0.5, 0.6, 0.8, 1.0, 1.2, 1.5
| 0.4, 0.5, 0.6, 0.8, 1.0, 1.3.
| 20, 31.75
| 5, 10
|
5”/ 125
| 0.5, 0.6, 0.8, 1.0, 1.2, 1.5
| 0.4, 0.5, 0.6, 0.8, 1.0, 1.3
| 20, 31.75
| 5, 10
|
6”/ 150
| 0.6, 0.8, 1.0, 1.2, 1.5, 1.8
| 0.5, 0.6, 0.8, 1.0, 1.3, 1.6
| 20, 31.75
| 5, 7, 10
|
8”/ 200
| 0.8, 1.0, 1.2, 1.5, 1.8
| 0.6, 0.7, 0.8, 0.9, 1.1, 1.2, 1.4, 1.5.
| 20, 31.75
| 5, 7, 10
|
12”/ 300
| 1.0, 1.2, 1.4, 1.5, 1.7, 1.8
| 0.7, 0.9, 1.1, 1.4
| 20, 31.75
| 5, 7, 10
|
16”/ 400
| 1.2, 1.5, 1.7, 1.8, 1.9, 2.0, 2.3
| 0.9, 1.2, 1.4, 1.6, 2.0
| 20, 31.75
| 5, 7, 10
|
20”/ 500
| 1.2, 1.5, 1.7, 1.8, 1.9, 2.0, 2.3
| 0.9, 1.2, 1.4, 1.6, 2.0
| 20, 31.75
| 5, 7, 10
|
Other size can be made according to customers’ requirement
|
– The slit is narrow, which can greatly increase the utilization rate of valuable raw materials
– Better elasticity: better buffer the plastic deformation of sample tissue brought by feed load, more flexible to adapt to metallographic cutting is constantly changing the cutting speed to adapt to the change of cutting torque output.
– Provide after-sales service.
– Technical support on usage.
– Return and exchange of products for non-human reasons.
