1000L 2000L 3000L Small Electric Heating Milk Batch Pasteurizer

US$2,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

MP-1000

Application

Liquid with Suspended Solids, Powder, Viscous Fluid, Liquid

Application Area

Daily Chemical

Certification

CE, ISO

Condition

New

Heating Method

Electric Heating

Mixing Drum Shape

Circular Groove

Stirring Type

Forced

Working

Shear Mixer

Name and Description

1000L 2000L 3000L Small Electric Heating Milk Batc

Electric Heating and Mixing Tank

for Milk, Juice, Beverage, Chemical

Heating Temperature

Can Reach to More Than 90centidegree

Material

Stainless Steel 304 /316

Mixing Speed

36rpm/960rpm//2900rpm

Product Application

Liquid, Food&Beverage Processing

Place of Origin

Shanghai China

Electric Heating Pasteurizer

Double Jacket Wall

Motor Brand

Siemens /ABB /China Brand

cleaning

CIP Spray Ball

Delivery

10 Days

Packing

Wooden Box

Voltage

Make It to Your Order

OEM

Yes

Spare Parts

Available

Mixer Type

Powder Mixer

Layout Type

Verticle

Operating type

Continuous Operating

Warranty

One Year

Transport Package

Standard Wooden Box

Specification

ISO

Trademark

KAIQUAN

Origin

Shanghai, China

HS Code

8479820090

Production Capacity

100units/Month

Product Description

1000L 2000L 3000L Small Electric Heating Milk Batch Pasteurizer
Small Electric Heating Milk Batch Pasteurizer
Mainly used for heating, mixing, pasteurizing, fermenting, preserving and storing fresh milk or other fresh liquid. It's the ideal HEATING, mixing pasteurizing and storage equipment for pasture, milk station, milk, and food and beverage factory and pharmacy industry.
TANK FEATURES
Heating by Electricity
* Type: With Jacket and insulation
* Internal shell thickness: 2 mm
* Jacket thickness: 3 mm
* Outer shell thickness: 1.5 mm
* Appearance: Ellipsoidal head top and down
Specification:
1. Electric heating
2. Jacketed with insulation layer
3. With or without mixing system. Mixing device: Paddle, Anchor, or spiral agitator (optional and changeable to meet customer demands).
4. Material: SUS 304 or SUS 316.
5. Outer casing surface: Mirror polishing / 2B original sub-gloss / 2B frosted sub-gloss; Inner surface (bladder and tank): Mirror polishing (Roughness: Ra≤ 0.4μ M ).
6. Liquid level gauge: Digital metre or glass gauge optional.
7. Thermometer: Optional. Temperature indication ranges from 0 to 100º C.
8. Sample valve optional
19. CIP cleaning: T-shaped 360° Rotational CIP cleaning ball.
10. Man-hole equipped.
Sanitary tainless Steel hree Phase Electric Heating and Mixing Tank

TankCapacity(L)	200, SS304	300, SS304	500, SS304	1000,SS304
REV	36r/min	36r/min	36r/min	36r/min
Electric motor of the agitator	0.55KW,380v,50hz	0.75KW,380v,50hz	0.75KW,380v,50hz	1.1KW,380v,50hz
Electric heating tube power	15KW,380v,50hz	18KW,380v,50hz	24KW,380v,50hz	45KW,380v,50hz
Heating Area(M2)	0.9	1.1	1.9	4.5
Material Input/output(DN MM)	38	38	38	50
OUTSIDE DEMENSION(LWH)MM	9009001600	100010001500	110011001700	140014001750
