Engine Type:
| Single cylinder,water-cooled, DOHC ,Four-stroke ,4 valves,Counterbalance shaft
| Front Suspension：
| 940±3mm、290mm、φ48mm、Adjustable
|
Displacement (ml):
| 250.2
| Rear Suspension：
| 408±2mm、80mm、φ12mm、Adjustable
|
Bore X Stroke (mm):
| 70x65
| Chassis structure :
| Material：Q235/Material：6061
|
Compression Ratio:
| 11:1
| Rear Swing arm：
| Alloy Material：6061
|
Max. Power (kw/r/min)
| 18/9000±500
| Handlbar:
| forgings and extrusions ,φ28↘φ22
|
Max. Torque (N.m/r/min):
| 21/8500±500
| Front Brake:
| Hydraulic twin piston Disc Brake
|
Max. Speed (Km/h):
| ≥110
| Rear Brake:
| Hydraulic single piston Disc Brake
|
Min. Fuel Consumption (g/kW.h)
| ≤354
| Front Tire:
| 80/100-21 (offroad tire); 110/70-17 (road tire)
|
Lubrication:
| Pressure ,splash
| Rear Tire:
| 110/100-18 (offroad tire); 140/70-17 (road tire)
|
Clutch Type:
| Manual, Multiplate wet clutch
| Muffler：
| Stainless steel exhaust pipe. Alloy muffler
|
Ignition:
| DCDI
| Steering Head Angle:
| Adjustable Steering system
|
Starting System:
| Electric
| Battery:
| 12V6.5Ah（dry battery）
|
Transmission System:
| Chain drive with 6 gears
| L X W X H (mm):
| 2184×832×1259
|
