Crawler Type Mini Corn Harvester Machine with Sun-Roof

US$21,500.00-25,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
4LZ-9
Harvest method
Picking
Drive Type
Vee belt
Transmission
Hard Shaft
Portable Harvester Type
Self-Propelled Rubber Track Full Feed
Certification
CE
Color
Red and White
Condition
New
Application Field
Agriculture
Warranty
1 Year
Trademark
WORLD
Origin
China
HS Code
84335100
Production Capacity
400000

Product Description

Feature:
It adopts advanced longitudinal axial flow structure, the drum length is 2.52m, and with 45ccHST, it is more labor-saving and improves the working efficiency. The threshing drum can be adjusted in three gears, and one machine can be used for multiple purposes. Luxury air-conditioned cab, high driving comfort.
Specification
Model 4LZ-9
Type Wheeled Self-propelled Whole-feeding
Dimension (Operation) Length(mm) 6550
Width(mm) 3200
Height(mm) 3350
Weight(kg) 5300
Engine Model Yuchai YC4DK150-T301
Power(HP) 160
RPM(r/min) 2600
Fuel consumption(kg/hm^2) 15~40
Fuel Capacity(L) 210
Gearbox Gearbox Box
HST HST 45cc
Chassis Tyre size Front tyre 15-24
Rear tire 10/75-15.3
Track Gauge(mm) Front 1900
Rear 1700
Wheel Base(mm) 2960
Ground Clearance(mm) 350
Harvesting Cutting Width(mm) 2750
Feeding Capacity (kg/s) 9.0
Cutting Bar Lift Hydraulic Control
Threshing Type Axial Flow Type with Beat Bars
Threshing Cylinder (mm) φ700*2520
Filtrate Type Vibrating Sieves+ Centrifugal Fan
Discharging Grain Tank Type Mechanical type
Grain Tank 2.8m³
Work efficiency(hm^2/h) 0.2-1.4
Crops Rice, Wheat, Soybean,corn
