Precision Tungsten Foil Sheet for Enhanced Electrical Applications

Product Description

Product Description
1. tungsten bar/tungsten rod/tungsten wire
2. Material Grade:Mo1/Mo2/MoW20/MoW30/MoW50
3.Standard: ASTM BS JIS NF DIN GB
4.Thickness: 0.1-10mm
5. Width:up to 1000mm
6.Process: cold rolled,hot rolled
The melting point of tungsten is the highest among all metals and the hardness is also high, so it is often used to produce heat-strength and wear-resistant alloys.
Because of its high density and high hardness, tungsten has become an ideal material for making high-density alloys. These high-density alloys are classified into W-Ni-Fe, W-Ni-Cu, W-Co, and W-WC according to their composition characteristics and uses. -Cu, W-Ag and other main series. These alloys have the characteristics of high specific gravity, high strength, strong radiation absorption ability, large thermal conductivity, small thermal expansion coefficient, good electrical conductivity, good solderability and processability, etc., and are widely used In aerospace, aviation, military, oil drilling, electrical instrumentation, medicine and other industries, such as manufacturing armor, heat sinks, counterweights for rudder control, and contact materials such as knife switches, circuit breakers, spot welding electrodes, etc.
Application
1.Electronic field
2.Chemical industry
3.Aerospcae
4.Aviation
5.Military
6.Oil Drilling
7.Medicine

	W	Ce	Th	Re	Ca	Fe	Mg	Mo	Ni	Si	C	N	Other
W1	balcance				0.003	0.005	0.002	0.01	0.003	0.003	0.005	0.003	Al0.002 O0.005
W2	balcance				0.003	0.005	0.002	0.01	0.003	0.005	0.008	0.003	Al0.004 O0.008
WAl1/WAl2	balcance				0.005	0.005	0.005	0.01	0.005		0.005	0.003
WCe0.8	balcance	0.65-0.98			0.005	0.005	0.005	0.01	0.003	0.005	0.01	0.003
WCe1.1	balcance	1.06-1.38			0.005	0.005	0.005	0.01	0.003	0.005	0.01	0.003
WCe1.6	balcance	1.47-1.79			0.005	0.005	0.005	0.01	0.003	0.005	0.01	0.003
WCe2.4	balcance	2.28-2.6			0.005	0.005	0.005	0.01	0.003	0.005	0.01	0.003
WCe3.2	balcance	3.09-3.42			0.005	0.005	0.005	0.01	0.003	0.005	0.01	0.003
WTh0.7	balcance		0.6-0.84		0.005	0.005		0.01	0.003		0.01	0.003
WTh1.1	balcance		0.85-1.27		0.005	0.005		0.01	0.003		0.01	0.003
WTh1.5	balcance		1.28-1.7		0.005	0.005		0.01	0.003		0.01	0.003
WTh1.9	balcance		1.7-2.13		0.005	0.005		0.01	0.003		0.01	0.003
WRe1.0	balcance			0.9-1.1	0.005	0.005		0.01	0.003		0.01	0.003
WRe3.0	balcance			2.85-3.15	0.005	0.005		0.01	0.003		0.01	0.003
