| US$14,000.00 | 1 Piece (MOQ) |
| Photograph | Performance Index | Performance Parameter |
| All pressure | 30T(adjustable) | |
| Temperature | room temperature ~300ºC | |
| Temperature controller | LED show temperature value | |
| Heating method | Electric heating | |
| Total power | 7 kW | |
| Power supply voltage | 3 phase , 380V | |
| Cooling method | Nature water cooling | |
| Accuracy between board | ±1ºC | |
| Accuracy temperature | ≤±1.0ºC | |
| Dissipation heat | ≤±1.5ºC | |
| Timer | LED 0~99(H) | |
| Size heating board | 300×300mm | |
| Size cooling board | 300×300mm | |
| Working floors | 2 | |
| Open model | auto | |
| Distance between board | 0~90mm | |
| Range of hydro cylinder | Max. 250mm | |
| Speed of hydro cylinder | 14mm/s | |
| Motor | 5 HP | |
| Safety part | position in the door | |
| Dimension (L×W×H) | 1550×1320×600mm |
