A2 A3 Size Dtf UV Printer with Visual Positioning Scanner Camera

Product Description

A2 a3 uv printer with ccd camera visual positioning
Product Description A2 size 4060 pvc visa card printing machine mobile phone skin cover UV printer that made by dosign digital technology, it can print on the glass, metal, plastic, acrylic, ceramic...etc. with vivid color and fast speed, it is really a good choice for entire level customers or kiosk using.
it was made with Chinese famous stable board system and installed 2 or 3 Pieces TX800 DX8 dx10 xp600 dx11 dx7 i1600 Printheads, can get max. printing speed by A4/50s, 6 color model, so can print on dark materials to get a good white ink density. And conbine with Maintop RIP software, can print all colors at one pass.
The dosign A2 UV Printer adopt aluminum alloy air vacuum adsorption table instead of glass table, durable and accurately for printing, and can adsorp slight materials keep flat on the table for printing
4060 UV flatbed printer use ball screw drive instead of belt drive for Z axis movement, much more precisely high resolution printing
dosign UV Printer led screen touch controller, friendly and convenient for operators use the UV Printer during printing. Can control for printhead and carriage move to left and right, the table up & down, forward and backward etc of the uv printing machine
UV LED Flatbed Printer use water circulation cooling system instead of use wind cooling system. Water cooling is more efficient and stable than wind cooling to longer the uv lamp lifespan up to 20000 Hours, and no uv light banding during printing
The A2 UV Flatbed Printer can use 2 or 3 pieces print head for CMYK, White +Varnish printing at the same time, the UV Printer can print out 3D embossed texture.
The UV Printing machine widely use in many industry, uv printer for decoration industry, signage printing industry, electronics industry, gifts industry etc.
Use imported HIWIN mute linear rail guide and Leadshine SERVO Motor, this guarantee the uv printer precisely straight running steps, and cowork with ball screw drive for the highest resolution printing
The max. materials height can up to 20cm 8.87in for almost all thickness materials printing, like luggage, box, even some full assembled items.
Product Parameters 2020 newest 40*60cm a2 2 or 3 print heads uv printer for printing on wood acrylic

Printer Model	A2 UV Printer DS-A2U Plus
Printing tech	Micro Piezo Technology 2 or 3 pieces DX8 TX800 dx11 xp600 DX7 G5i printheads
Printing Size	A2 Size 400*600mm 15.74*23.6in
Print resolution	2160dpi
Accepted material's height	15CM
Print quality	True Photographic quality
Printing direction	Smart Bi-directional Printing Mode
Printing speed	720 dpi 50 seconds/A4 size
	1440 dpi 100 seconds/A4 size.
Applicable industry	Rigid PVC board, glass, plastic, organic board, leather, rubber, specialpaper, metal, wood, porcelain, PVC, ABS, acrylic, aluminum, iron sheet, ceramic tile, glass, marble, granite, paperboard, AB Crystal sticker pet film etc
Max Media weight	10 KGs NET.
Operating system	Windows XP/ME/Vista/Win7/Win10
Interface	USB
Languages	English
Ink colors	C, M, Y, K, White / Varnish
Ink type	UV LED ink
Ink supply	250 ml/bottle
Height adjustment	Automatic
Driving power	110 V/ 220 V.
Power consumption	36 W/ Hour.
Ink consumption	15 ML/SQM.
Software	Maintop, CorelDraw, Illustrator,
RIP Software	Free RIP software can print all colors at one time
NW/GW	80KG/120KG
Machine Size	820mm x 625mm x 430mm
Packing Size	1450mm x 1270mm x 900mm

Detailed Photos
Smart easy operation LED display control pannel
(can operate the printhead move from left to right, table move forward and backward, table up and down)
Automatic lifting and down capping
Ink bottles( include low ink alarming system, white ink circulation system)
Automatic media sensor for precise height for printing
Z axis ball screw drive(much more precisely than belt drive)
White ink stri button & Low ink alarming system for each ink bottles.
This ink system protect the printhead and convenient for users Continuous printing
2 UV LED Lamps more effecient and dry fast. One for KCMY+White head, another for Varnish head
Applications:
Customers Family:
FAQ:
(1) Q: 1.How long is your delivery time? A: Generally it's 5 days to made and tested well the machines for you, and then arrange shipment for you.
(2) Q: 2. How about the products quality?
A: To ensure our quality, all product have to go through and pass series of tests, including printing test, life test,etc.
(3) Q: 3. Can you provide OEM service for the customer?
A: Yes, we provide OEM service for our customers.
(4) Q: 4. What's your terms of payment?
A: Payment within $1000, 100% in adcance. Payment more than $1000, 30% T/T, balance before shipment.
(5) Q: 5. Can I get printing sample from you?
A: Yes, free printing samples will be prepared well for you. If the materials not in hand in demo place, you'd better let your China supplier send the materials to us. And the courier freight is on your side.
