HTC6180-1000mm Horizontal CNC Lathe Machine with Fanuc Controller

Product Description

Quick Delivery for Economical Fast Speed Flat Bed CNC Horizonal Lathe machine with SIEMENS808D/FUNUC
Tell us the size, material Details of your workpiece. And If there are some Workpiece drawing available ,it will be better. Our Technician team will receommend you the most economical and suitable machine Solutions in a short time.
The main performance characteristics: Widening high stability bed Two gear spindle speed,stepless in gear Wider layor board Intergrated automatic lubrication system Application: The machine is suitable to process all kinds of small and middle-sized shaft and plate workpiece,and could also turn various threads ,circle arc ,circle cone ,inside and outside surface of revolved body .This machine is widely used in sanitary ,value ,electrical appliance ,instrument ,automobile ,motor cycle ,bearing and so on.
Main Technical Specifications for Hot Sale Lathe machine.

Specifications	Unit	HTC6140D
Max.swing over bed	mm	Ф400
Max.swing over cross slide	mm	Ф210
Distance between centers	mm	750/1000
X/Z axis travel	mm	X:260 Z:750/1000
Spindle transmission type		Independent Spindle transmission ,in gear variable speed
Spindle speed steep		variable
Spindle speed	rpm	100-3000
Spindle nose		A2-5
Thru-hole dia.of spindle	mm	56
Spindle taper		MT6
Spindle motor	KW	7.5
Chuck size	mm	250
Ball screw dia.and pitch	mm	φ20X4/φ40X6
X/Z axis feed motor torque	N.m	X:6 Z:10
X/Z axis feed motor power	KW	X:1.5 Z:2.5
X/Z axis fast moving speed	mm/min	X:4000 Z:5000
X/Z axis Position accuracy	mm	0.02/0.025
X/Z axis repeatability	mm	0.01/0.015
Processing accuracy		IT6-IT7
Workpiece surface roughness		Ra1.6
Tailstock sleeve dia.	mm	75
Tailstock sleeve travel	mm	140
Tailstock sleeve taper	#	MT5
Guide form		Spindle mountain+flat rail
Total power capacity	KVA	10
Machine dimension(L×W×H)	mm	2000X1050X1500
G.W.	kg	2000/2500

Other Model List of the Slat Bed CNC Lathe You can Select.

Model	Remark	Swing dia.×Z travel -spindle bore(mm)
HTC0640	LM guide	Φ300×200-Φ48.5
HTC0620	Closed guide	Φ200×200-Φ37
HTC6125	Closed guide	Φ250×300-Φ48
HTC6130	Wide guide	Φ300×350-Φ48
HTC6132	Wide guide	Φ320×450-Φ50
H6135	6 class gear	Φ350/400×750/1m-Φ46
H6136	Spindle unit	Φ420×750-Φ58
H6150A	3 class gear	Φ520×1/1.5/2m-Φ82
H6140C	Spindle unit	Φ420×750/1m-Φ66
H6150B	3 class gear	Φ510×1/1.5/2m-Φ82
H6150C	Spindle unit	Φ510×1/1.5/2m-Φ86
H6166C	Spindle unit	Φ660×1/1.5/2m-Φ112
H6163	3 class gear	Φ630×1~6m-Φ100
H6180	3 class gear	Φ800×1~6m-Φ10

---
