Four Colors Paper Cup Printing Machine with Durable Function

Product Description

Product Description Details of CY-950-4 Paper Printing Machine:
1)Adopt the anilox to spread ink.
2)Unwinding and rewinding are controlled by magnetic power brake, clutch, lor by automatic tension controller of Mitsubishi, made in Japan.
3)Each printing unite adopts 360-degree registering adjuster.
4)Each printing unite have one IR drier.
5)The inking roller can break away automatically while paking, and running at a low speed, in order to avoid ink being dry.
6)The main motor is adopted the import stepless regulation of frequency conversion.
7)Unwinding, web guiding, corona discharging, printing, IR drying and rewinding can be finished in one process, this is an ideal machine to print many kinds of paper cup.
Product Parameters Main Technical Parameter:

Speed	60m/min
Max Printing Width	850mm
Power Supply	380v50hz or customized
Printing Gidth	180-240mm
Max Web Width	860mm
Weight	3800kgs
Dimension	3500*1850*2200mm

Company Profile COMPANY INFORMATION:
WENZHOU TOPPRO machinery co., ltd, was formerly known as the Ruian Sincere machinery Co., Ltd. It is manufacturer of the paper container forming machine like paper cup making machine, paper bowl forming machine, ice cream cone sleeve machine, die cutting machine etc. CE, and SGS were passed. In the last decade, the overseas market was explored and the machines were exported.
" Quality first, Service paramountcy! " is the faith of the company, and it inspired us to offer higher quality and a better service. Your visit to my company are highly appreciated. We are looking for the cooperation with you in the near future!
OUR SERVICES:
WARRANTY: 12 MONTHS( Since the machine left the company)
Engineers are availale to service the machinery overseas.
FAQ FAQ:
Q1: What is the difference between my machine and the machine from other company?
Four shafts we use is 30 mm diameter.
While other companies use 25 mm diameter.
All our machine use big 125# gear box, machines can work stably than normal type.
Q2: If the machine break down overseas, what is the effecient to solve the problem?
Basially, the machine is easy to operate, the engineer can teach the client how to fix the machine by video or email. And the engineer are available to overseas.

---
