The advantage of 3Axles 60Tons Side Wall Cargo Semi Trailer1. The vehicle body is made of high-quality steel, advanced technology and strict production.
2. The whole vehicle structure is reasonable, the performance is reliable;
3. The operation is simple and the exterior appearance is beautiful;
4. The structure of suspension is reasonable and has strong rigidity and strength, which is used to support the load to slow down the impact.
Tare Weight
| 9500kg
|
Overall Length
| 12400mm
|
Overall Width
| 2480mm
|
Payload
| 60000kg
|
I Beam& Chassis
| Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm,Height 500mm, Bottom Flange 16mm,width 140mm.
|
Axle
| 3 axles
|
BPW Brand 13 ton
|
Suspension
| Heavy duty mechanical suspension
|
Floor
| 3mm checker plate
|
Leaf Spring
| 13 piece Leaf spring for heavy loading
|
King Pin
| JOST brand 2” Bolt-in King Pin
|
Landing Gear
| JOST brand Two-speed, manual operating, heavy duty landing gear
|
Wheel Rim
| 8.25-22.5 wheel rim
|
Tire
| 11R22.5 tire with one spare tire
|
Twist Lock
| 12 nos. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container, there tractable central locks can be laid down.
|
Spare Tire
| One set of spare tire including a carrier
|
Braking System
| WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks
|
Painting
| Complete Chassis sandblasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint
|
Accessories
| One standard tool box
|
