Standard Schwing DN200X2125 Truck Mounted Concrete (Cement) Delivery (Convey) Cylinder

Product Description

PM/SCHWING /ZOOMLION Pump Cylinder

Putzmeister
Outer Diameter(mm)	Inner Diameter(mm)	length(mm)	Travel(mm)
305	280	2355	2200
278	250	2710	2500
278	250	2310	2100
254	230	2320	2100
254	230	1600	1400
219	200	2305	2100
219	200	1585	1400
203	180	2305	2100
Schwing
Outer Diameter(mm)	Inner Diameter(mm)	length(mm)	Travel(mm)
270	250	2635	2500
270	250	2135	2000
251	230	2125	2000
251	230	2133	2000
253	230	1175	1000
219	200	2125	2000
219	200	1775	1600
210	180	2125	2000
203	180	2125	2000
202	180	1775	1600
200	180	1520	1400
196	180	1320	1200
200	180	1175	1000
Outer Diameter(mm)	Inner Diameter(mm)	length(mm)	Travel(mm)
280	260	2345	2200
280	260	2245	2100
280	260	2145	2000
280	260	2045	1900
258	230	2146	2000
258	230	1946	1800
258	230	1746	1600
226	200	1946	1800
226	200	1746	1600
226	200	1546	1400
Zoomlion
Outer Diameter(mm)	Inner Diameter(mm)	length(mm)	Travel(mm)
280	260	2250	2100
250	230	2250	2100
258	230	1800	1600
219	200	1960	1800
219	200	1800	1600
219	200	1587	1400

FAQ:
1.HOW LONG CAN I GET THE FEEDBACKS AFTER WE SENT THE INQUIRY?
We will reply you within 12 hours in working day.

2.ARE YOU A DIRECT MANUFACTURER OR TRADING COMPANY?
We are MANUFACTURER

3.WHAT PRODUCTS CAN YOU OFFER?
We focus on concrete pump spare parts.

4.WHAT APPLICATIONS DO YOUR PRODUCTS RELATE TO?
Our products cover a wide range of industries including concrete pump & automobile & truck, construction machinery, mixer truck, building, hardware and so on.

5.CAN YOU DO CUSTOMIZED PRODUCTS?
Yes,we are mainly doing customized products according to the customers' drawings or samples.

6.DO YOU HAVE SOME STANDARD PARTS?
Yes,We are manily in concrete pump OEM standard parts,also can call it as construction machinery.

7.HOW TO GUARANTEE THE QUALITY OF YOUR GOODS?
Firstly,we will do the inspection after every process.For the finished products,we will do 100% inspection according to the customers' requirements and the international standard.

8.WHAT'S THE PAYMENT TERM?
When we quote for you,we will confirm with you the way of transaction,FOB,CIF,CNF,etc.
For mass production goods, you need to pay 50% deposit before producing and50% balance after we packed but before shipping .The most common way is by T/T. L/C is also acceptable.

9.HOW TO DELIVER THE GOODS TO US?
Usually we will ship the goods to you by sea,we also could sent out by air ,both are very convenient .

10.WHERE ARE YOUR PRODUCTS MAINLY EXPORTED TO?
Our products are mainly exported to over 30 countries such as Mexico,Malaysia,Japan,Chile,Jordan,Iran,Turkey,Lebanon,Thailand and etc.

---
