STARDRAWING 15ton Load ISO Container Self Loading Trailer Lifting Wheel System

Product Description
STARDRAWING 15ton Load ISO Container Self Loading Trailer Lifting Wheel System
Containers are often used as a mobile system for a wide variety of applications. For example, these applications range from simple work station office and equipment storage containers to highly complicated communications, medical and radar unit containers. All of these mobile systems need to be loaded to convey them to their site of use, and then unloaded, moved into place, and levelled to ensure that they work properly that is precisely what our durable and reliable self loading wheel mover systems are built to achieve. This wheel system is connected into the bottom ISO corner castings with the upper beam resting on the corner post of the container. Each wheel system comes complete with four corner units with handle bars, connecting rods, steering system, tow bar, and a storage/transportation stand. When connected, it is possible to move containers in all directions.


Main Features
1) Quick and easy to attach into the DIN 1161 ISO-corners of container2) A compact transport rack with all the necessary equipment installed 3) Available to move a container in any direction 4) Very strong and durable construction 5) Towable using with almost any vehicle 6) Solid rubber as wheel material option 7) Independent of cranes and forklifts 8) Enables easy movement, even in some narrow places with a restricted height 9) Human hand bar driving, with just two people required to raise or lower the load with minimum effort 10) Please contact us to get an operation manual and video 11) This wheel system is very easy to operate, don't need a familiarisation training. 12) Color painting can be as your request.
Product Parameters

Wheel Diameter (MM)	Tire Tread Width (MM)	Load Capacity/Per Set (TON)	Lifting Height (CM)	Max Speed (KM/H)
541	160	15	35	10

Applications
Our this ISO container moving system makes lifting and transporting an ISO container simple, with just two people required to raise or lower the load with minimum effort. Once the wheels are attached to the lower corners of the shipping container, it can be pushed or pulled (towed) by a suitable vehicle at speeds of up to 10KM/H. This product can also help transport a container into a cargo airplane with its compact body size. Please notice that the wheel system is not suitable for towing on public roads, very uneven roads, and very soft roads. This wheel system does not have its own braking system, so towing is suggested only with tow vehicles that have sufficient weight and braking power for the towed system.
Packaging & Shipping

Testing Machine
FAQ
Dear : Can I get free caster wheel samples from Stardrawing ?
STAR : We would be honor to offer you free caster samples, and we believe that you would be willing to pay for the freight fee for such good products. Please provide your DHL/FedEx or other freight collect number and advise which express type should be chosen, international express type(2~3days) or economic type (4~5days).
Dear : What is your payment terms of caster ?
STAR : It is undisputable and crystal clear that 30% advanced payment, 70% before shipment, hope we have reached agreement for this regular payment manner. Dear : What about your lead time ?
STAR : Usually, caster sample needs 5-7 days, mass production time needs 30 days. It is up to the quantity and stocking. Dear : Is it OK to print my logo on casters ?
STAR : Sure.
Option 1 - Build the molds and fixtures upon your sample or technical drawings
Option 2 - Add your logo on fork or wheel
Option 3 - Pack the casters in your branded carton
Dear : How can I trust the quality of your casters ? STAR : We tell you that we have variety of international quality certificates, we have a very strict quality control system, we do a series of caster tests before shipping. Right, you still have no idea about our quality. Therefore, no hesitate! Just place a trial order from Stardrawing. You will not only trust the quality of casters, but also trust the character of Stardrawing people since then.

---
