| US$400.00-700.00 | 1 Piece (MOQ) |
| Mainboard | Supports Mini-ITX motherboard, built-in EC7-1821 | |
| CPU | EC7-1821 : H110 chipset, supports Intel LGA1151 6th&7th I3/I5/I7 Core Processor, Intel Pentium Processor, Intel Celeron Processor (G3900 as standard spec) | |
| Memory | 1 x DDR4 U-DIMM slot, support up to 16G | |
| I/O | In Rear: 2 x USB3.0, 2 x USB2.0 4 x COM (COM1~COM2 support RS232/422/485); 1 x VGA, 1 x HDI 2 x Lan ( support POE function by POE power module ) 1 x ATX power supply socket; 1 x Audio: Line-in/Line-out 1 x 16bit GPIO by DB44 pin header In front: 2 x USB2.0; Power switch; Phoenix terminal interface is used to connect with the front power Note: 1 x PCIEx16 (2 x PCI or 1 x PCIEx16 or 2 x PCIE *8 or 1 x PCIE *8 +1 x PCI expandable by expansion board); POE function of LAN ports can be come true by POE power module; Not including any expansion board in our standard configurations. | |
| Storage | Hard disk | 1*2.5" HDD (shock absorption effect) |
| Optical drive | Don't support | |
| Expansion | 1*PCIe x16 | |
| Working environment | 0~50ºC; 5~90% (non-condensing) | |
| Storage environment | -20~60ºC; 5~90% (non-condensing) | |
| Power | Mini ATX industrial grade power supply, 200W ATX power supply as standard | |
| Dimension (W*H*D) | 250*210*88 mm | |
| Part Number | Model Number | Description |
| 0010-114851 | IPC-520S-01 | 2U,small size computer IPC-520S/ EC7-1821-H110/I3-6100 / 4G memory / 500G HDD /ATX 200W power supply / No ODD /No keyboard or mouse / External I/O ports: 2 x LAN(supportPOE function through expansion ) / 6 x COM (4 x external ports, 2 x built-inpin headers) / VGA+HDI / 6 x USB(2 x USB3.0, 4 x USB2.0), 1 x built-in USB3.0pin header, 1 x vertical USB3.0 slot / 1 x Audio / 1 x 16bits GPIO pin is ledout in DB44 style through the lead cable / 1 x PCIe x 16 (Actual speed x 16).The motherboard in the chassis: EC7-1821-H110, (with heat dissipation holes onthe top of the chassis) |
| 0010-114861 | IPC-520S-02 | 2U,small size computer IPC-520S/ EC7-1821-H110/I5-6500 / 4G memory / 1T HDD / ATX200W power supply / No ODD /No keyboard or mouse / External I/O ports: 2 x LAN(supportPOE function through expansion ) / 6 x COM (4 x external ports, 2 x built-inpin headers) / VGA+HDI / 6 x USB(2 x USB3.0, 4 x USB2.0), 1 x built-in USB3.0pin header, 1 x vertical USB3.0 slot / 1 x Audio / 1 x 16bits GPIO pin is ledout in DB44 style through the lead cable / 1 x PCIe x 16 (Actual speed x 16).The motherboard in the chassis: EC7-1821-H110, (with heat dissipation holes onthe top of the chassis) |
| 0020-062731 | IPC-520S barebone system | EC7-1821-H110-01/No CPU/No Memory/No HDD/ ATX 200W power supply/No Optical drive/ 2 x Lan/6 x COM(2 of them by pin header on motherboard)/ 1 x VGA/1 x HDI/6 x USB(2 x USB3.0, 4 x USB2.0)/ 1 x USB3.0 pin header and 1 x USB3.0 vertical slot on motherboard/ 1 x Audio/1 x 16bit GPIO DB44 pin header/1 x PCIE*16 (x16 connector) |
| 0020-062741 | IPC-520S barebone system-01 | EC7-1821-C236/No CPU/No Memory/No HDD/ ATX 200W power supply/No Optical drive/ 2 x Lan/6 x COM(2 of them by pin header on motherboard)/ 1 x VGA/1 x HDI/6 x USB(2 x USB3.0, 4 x USB2.0)/ 1 x USB3.0 pin header and 1 x USB3.0 vertical slot on motherboard/ 1 x Audio/1 x 16bit GPIO DB44 pin header/1 x PCIE*16 (x16 connector) |
| Part Number | Model Number | Description |
| 0060-005061 | EB-X16-020 PCI IO Board | For expanding PCI interface full height half size expansion card (2 x PCI) |
| 0060-005051 | EB-X16-100C PCIE IO Board | For expanding PCIe interface full height half size expansion card (1 x PCIE-16) |
| 0090-005271 | 2 * PCIE x8 IO board (EB-X16-200B) | For expanding PCIE*8 interface full height half size expansion card (2 x PCIE-8) |
| 0090-005281 | 1*PCIE x8+1*PCI IO board (EB-X16-110B) | For expanding PCIE*8+PCI interface full height half size expansion card (1 x PCIE-8 + 1 x PCI) |
| Mainboard | ECS-1839V2NA (H110 Chipset) | |
| CPU | Support Intel LGA1151 6th/7th Gen i3/i5/i7 Core Processor, Intel Pentium/Celeron CPU | |
| Memory | 2*DDR4 1866/2133MHz DIMM slot, 16GB single slot, max up to 32GB | |
| I/O | 10 x USB (4 x USB3.0, 6 x USB2.0); 6 x COM (COM1 and COM2 support RS232/RS422/RS485; Expandable for another 2~4 COM ports by LPC bus pin header); VGA, HDI,DVI-D 2 x LAN 1 x LPT 1 x 8bit GPIO 1 x Audio (MIC-IN/LINE-IN/LINE-OUT) | |
| Storage | Hard disk | 1*2.5" HDD bay, 1 x HDD as standard spec(4 x SATA3.0 ports on motherboard) |
| Optical drive | 1*optical drive bay (compatible for installing HDD) | |
| Expansion | 2 x PCI, 1 x Pcle x4, 1 x Pcle x16 | |
| Working environment | 0~50ºC; 5~90% (non-condensing) | |
| Storage environment | -20~80ºC; 5~90% (non-condensing) | |
| Power | Small size PS2 ATX power supply , or 1U power supply | |
| BIOS | AMI EFI BISO, motherboard AMI BIOS support BPI technology, | |
| OS | WIN7, WIN8.1, WIN10,Cent OS Linux, Red Hat®Enterpr. Ise linux | |
| Part Number | Model Number | Description |
| 0010-106041 | IPC-620H/ECS-1839/G3900/4G/500G/300W | IPC-620H-H110/H110/ECS-1839/G3900/4G DDR4/500G HDD/ ATX 300W/6*COM/8*USB/2*GbE/1*VGA/1*HDI/1*DVI-D/ 1*LPT/1*Audio/2*PCI/1*PCle x4/1*PCle x16 |
| 0010-106051 | IPC-620H/ECS-1839/I3-6100/4G/500G/300W | IPC-620H-H110/H110/ECS-1839/I3-6100/4G DDR4/500G HDD/ ATX 300W/6*COM/8*USB/2*GbE/1*VGA/1*HDI/1*DVI-D/ 1*LPT/1*Audio/2*PCI/1*PCle x4/1*PCle x16 |
| 0010-106061 | IPC-620H/ECS-1839/I5-6500/4G/1T/300W | IPC-620H-H110/H110/ECS-1839/I5-6500/4G DDR4/1T HDD/ ATX 300W/6*COM/8*USB/2*GbE/1*VGA/1*HDI/1*DVI-D/ 1*LPT/1*Audio/2*PCI/1*PCle x4/1*PCle x16 |
| 0010-106071 | IPC-620H/ECS-1839/I7-6700/8G/1T/300W | IPC-620H-H110/H110/ECS-1839/I7-6700/8G DDR4/1T HDD/ ATX 300W/6*COM/8*USB/2*GbE/1*VGA/1*HDI/1*DVI-D/ 1*LPT/1*Audio/2*PCI/1*PCle x4/1*PCle x16 |
| 0020-062121 | IPC-620H barebone system/ECS-1839/300W | IPC-620H-H110 Barebone/H110/ECS-1839/No CPU, RAM, HDD/ ATX 300W/2*COM/8*USB/2*GbE/1*VGA/1*HDI/1*DVI-D/ 1*LPT/1*Audio/2*PCI/1*PCle x4/1*PCle x16 |
