Industrial Palm Complete Automatic Red Palm Fruit Oil Extraction Plant for Oil Milling Extraction Pressing Milling

Product Description

10-200TPD palm fruit oil processing machine crude palm oil production line extraction machine plant with low cost

Processing procedures of Palm fruit oil press machine line crude palm oil production line: Diesel Generator→ Steam Turbine→ Reception Station→ Palm Oil Plant Sterilizing Station→ Thresher→ Press Station→ Pressing station→Screen Filter→ Decanter Centrifuge→Vacuum Dryer→ Sewage Treatment
Our company is specialized in palm oil extraction machine, we can provide the palm oil extraction machine from 10 ton to 3000 tons per day capacity.
Product Paramenters

Project name	capacity	suitable for raw material
oilseeds pretreatment project	10-5000T/D	sunflower seed, soybean, peanut, sesame, corn germ, tea seed, rapeseed, cottonseed, etc
oilseeds extraction project	30-5000T/D	pressed oil cake, soybean flakes, rice bran pallet, etc.
crude oil refining project	10-1000T/D	all kinds of vegetable oil, animal oil, etc.
Palm oil mill	1T/H-90T/H	palm fruit bunch
Palm oil refining and fractionation project	10-1000T/D	refined palm oil
Oilseeds protein, phospholipids	50-500t/d	soybean meal, etc.
Natural pigment extraction production line	30-500t/d	piment, vegetable , etc
grain deep processing line	20-1000t/d	corn, wheat, beans, etc.

Edible Oil Processing Equipment

Soybean, Sunflower, Cotton Seed, Rapeseed, Rice Bran, Palm Fruit, Coconut, Corn Germ

Groundnut/Peanut, Sesame, Castor, Pepper, Lemon, Grapeseed

Biodiesel Oil Processing Equipment

Waste vegetable oil, Animal fat, Seaweed, Palm oil

Essential Oil & Cosmetics oil Processing Equipment

Avocado oil, Moringa oil, Almond oil, Other Essential oil

Cereals Milling Machine

Maize Milling Machine, Wheat Milling Machine, Other Cereals Milling Machine

Protein Treatment Machine/Engineering

Cotton seed protein, Soy protein isolate/ concentrate, Other protein Treatment

Animal Feed Machine

Chicken Feed, Cattle feed, Goat & sheep feed, Pig feed, Aquafeed and other animal feed

Feed Milling Machine, Feed mixer, Feed pellet machine

After transport the FFB to palm oil mill, the fruits will go to sterilizer by conveyor or palm fruit cage. After separating palm fruits and palm bunch by thresher, Pam fruits will be conveyed to palm oil presser to get CPO. Palm bunch can be used as fertilizer or fuel. After pressing, we can get palm cake and palm nut. Pam nuts will be conveyed to palm recovery system to get palm kernels, fiber and palm shell. Palm cake will be conveyed to boiler room as fuel. After filtering, centrifuging, vacuum drying, we can get crude palm oi (CPO), the CPO can be sold directly or used for further processing. The sewage from all the plant will be processed by sewage treatment to reach discharge standard. Sludge can be used for fertilizer in palm plantation. All the process cycle features with short operation cycle, high automaticity, energy conservation and environmental protection.
1.palm oil extraction machine Introduction:
a. Palm fruit reception:
Transport FFB to reception station, flow to the scraper conveyer, conveyed to sterilizing station.
b. Sterilizaiton:
FFB transported by scraper conveyer fall into sterilizing tank, make FFB soft,get more oil yield. sterilizing time 90~120mins, temperature 130~145°C
c.Threshing:
After sterilizing, fruit bunch transported to thresh machine, separate palm fruit and empty fruit bunch.
d:Digesting:
Before press palm fruit, should be crushed separated pulp and kernel
e.Oil press:
After crushing and digesting, the maxture of palm fruit and kernel fall into special palm oil presser
f.Clarification:
Filter the oil and use centrifuge to separate oil and impurities.
g. Kernel recovery:
After press, the kernel and cake will be transported to kernel recovery station. Separating nut and shell, then go to kernel oil press.
2. palm oil refinery & fractionation workshops.
(1)Degumming: This is the most important section of hydrate de-gumming, manage the adding water (there is a little P-acid in the water) amount, temperature and add water speed, usually water adding amount is about 3 times of phospholipid content, that is 3-10% oil weight, water temp needs to be higher than oil temp.
(2)Deacidification:This part adopt alkali refining method, that is use alkalis like (NaOH) to neutral the free fatty acid in oil, during this process it will produce soapstock , then separated from the oil by setting several hours. NAOH solution, not only neutral free fatty acid, also can act with other matters like protein, mucus, phospholipid, pigment. After settling, release the soapstock from the tank bottom. Adding hot water to rinse, remove off the leftover lye , soap and some unhydrated phospholipid in the oil. Finally pumping out soapstock from the tank bottom
(3)Decolorization: In normal situation , there is pigment in the crude oil , we need to using the active clay to absorb the pigment away , after 20 mins , we use the vibrating filter to filter the waste clay away . If you want to get light color oil , you need to add more active clay . That is mean , the customer can accord to his requirement to control the oil color. This process is carried out under the vacuum condition.
What is oil palm oil fractionation plant?
Oil is consist of triacylglycerol with different melting point under a temperature, separate the olein and stearin by their different melting point (melting tem33ºC-39 ºC,faint yellow color) and melting percentage, this is oil fractionation.
Significance of palm oil fractionation plant
1.effect the oil use value: for making food product like shortening and margarine etc, if the olein in oil is low, the food will be more stable, and can storage longer time.
2.Some first grade vegetable oil has a strict demand on the clarity, if the stearin is high in oil, the oil will seems cloudy
After the refined palm oil is fractionated, you can get two parts:
(Palm) Olein is used for edible oil, frying oil.
(Palm) Stearin is used for shortening oil, pastry, butter, soap and chemical product.
3.Palm oil production process drawing
4.Other photos:

---
