| US$40,000.00 | 1 Piece (MOQ) |
| Performance of mixing drum | Geometric volume | m³ | 23.5 |
| Mixing volume | m³ | 15 | |
| Maximum diameter of drum body | mm | 2432 | |
| Length of mixing drum | mm | 7009 | |
| Angle of inclination | ° | 10 | |
| Rotating speed | r/min | 0~14 | |
| Charge speed | m³/min | ≥3 | |
| Discharge speed | m³/min | ≥2 | |
| Residue ratio of discharge | % | <0.7 | |
| Range of slump | cm | 5~21 | |
| Hydraulic system | Oil pump | international brand | |
| Motor | international brand | ||
| Reduction gears | international brand | ||
| Hydraulic circuit | Closed type | ||
| Water supply | water tank capacity | L | 450 |
| Way of water supply | Pneumatic | ||
| Complete machine | Brand of chassis | NAC | |
| Chassis model | SX5315GJBJT346 | ||
| Type of driving | Left-hand drive | ||
| Curb weight | kg | 17000 | |
| maximum gross weight | kg | 31000 | |
| Type of drive | 8×4 | ||
| Wheel base | mm | 1800+3375+1400 | |
| Tyre | 12.00R20 | ||
| Means of power takeoff | Power takeoff by flywheel | ||
| Notice model | XZJ5310GJB2 | ||
| External dimensions | (length×width×height)mm | 11910×2500×3995 | |
| Engine | Model | WP10.375/WP10.380E32 | |
| Rated power | Kw/r/min | 276 | |
| Displacement | L | 9.726 | |
| Emission standard | GB III |
