Based on All Steel Substrate Ceramic Anti-Static Access Floor for Laboratories and Electronic Factories

US$7.00-10.00 1 Piece (MOQ)

Basic Info.

Model NO.
LD601B
Material
Calcium Sulphate
Size
600*600mm
Function
Thermal Insulation, Anti-Fouling, Fireproof, Soundproof, Waterproof, Anti-static
Surface Treatment
UV Anti-Static HPL
Color
White
Metal Type
Steel
Certification
CE, ISO, ASTM
Usage
Electrical Factory, Computer Room, Bank, Offices
Advantage
Easy to Clean
Customized
Customized
Transport Package
Pallet
Specification
600*600mm and Other Special Size
Trademark
LD
Origin
Changzhou, Jiangsu, China
HS Code
3918909000
Production Capacity
111111pieces/Year

Product Description

Introduction:
Ceramic anti-static panels use a steel or calcium sulfate base with a 10mm ceramic veneer on top and conductive adhesive strips on the edges. With a total thickness of 40mm or 45mm, these panels are popular for their easy cleaning, durability, and decorative appeal. Specifications and Material:
Specifications: Panel Size: Standard 600mm x 600mm, customizable. Panel Thickness: Options of 35mm, 40mm, and 45mm. Load Capacity: Strong load-bearing capacity. Surface Finish: Powder-coated or galvanized steel. Material:
Base materials include calcium sulfate boards, offering excellent strength, corrosion resistance, and anti-static properties. Ceramic veneers are wear-resistant, easy to clean, come in a wide variety of veneers, and are highly decorative. Performance Features: The ceramic veneer is abrasion-resistant and easy to clean. The anti-static ceramic veneer has a Mohs hardness of 7 and lasts over 60 years. Various ceramic veneers offer strong decorative effects and diverse aesthetics. Base materials include full steel, calcium sulfate, and high-density boards. Applications:electronic factories, computer rooms, data centers, laboratories, and clean rooms.
Core Competencies: Tailored design and customization for specific needs. Advanced manufacturing technology ensuring high quality. Cost-effective solutions without compromising performance. Quick installation and easy maintenance. Product Parameters:
Type Size Concentrated Load Uniform load Ultimate Load System Resistance Fire Resistance
N KG LB N/M2 LB/SQFT
LD601B 600*600*40/45 ≥2250 230 506 ≥12500 261 ≥8850 1.0×106-8Ω A1

Production Process: Select substrate Steel plate cutting Composite stamping Packaging Finished product stacking
