Sg-450 Saw Blade Sharpening Machine with High Accurate

US$1,700.00 1 Piece (MOQ)

Basic Info.

Model NO.

SG-450

Abrasives

Grinding Wheel

Controlling Mode

Artificial

Automatic Grade

Semiautomatic

Cylindrical Grinder Type

Universal Cylindrical Grinder

Precision

High Precision

Condition

New

Suitbale Products

Circular Saw Blade

Transport Package

Wooden Case

Specification

450mm

Trademark

Baorui

Origin

China

HS Code

8460390000

Production Capacity

3000 PCS/ Year

Product Description

SG-450 saw blade sharpening machine, can sharpening and chamfering saw blade with many types teeth, fast speed, high accurate
Technological data

Item	Name	Data
1	Saw blade outer diameter	Φ50mm-Φ450mm
2	the teeth distance	25mm
3	teeth depth	8mm
4	cutting degree	-5°- 30°
5	feeding speed	45-180 teeth/ minute
6	saw blade thickness	8mm
7	grinding wheel diameter	Φ75mm-Φ150mm
8	grinding wheel speed	4200RPM
9	the motor power	1/2HP
10	the grinding wheel power	3/4HP
11	Micro section adjusting angle	±20°
12	Rotary corner	30° left, 45°right
13	machine size	800mm x 800mm x 1410mm
14	weight	130kgs
15	Warranty time	12 months
