| Specification | Unit | X6332A |
| Table size | mm | 1370*320 |
| Table travel X/Y/Z | mm | 820/300/400 |
| Spindle taper | | ISO40(H,V) |
| Max turning angle of working table | deg | ±45 |
| Tilt angle for milling head | deg | left and right ±45 |
| T-slot number/width | | 3/14mm |
| Arbor dia. | mm | 27 |
| Disance from horizontal spindle center to table | mm | 75-475 |
| Disance from spindle nose to table | mm | 160-560 |
| Distance from spindle axis to ram surface | mm | 200 |
| Spindle speed range | r/min | 65-4660(V) 35-1500(H) |
| Feeding range of longitudinal, cross travel | mm/min | 30-830 |
| Auto-feeding of Z-axis | mm/min | 23-625 |
| Rapid feed of longitudinal, cross travel | mm/min | 1335 |
| Rapid feed of Z-axis | mm/min | 1000 |
| Horse power for main motor | kW | 3.7(V) 3.0(H) |
| Overall dimensions | mm | 1900*1750*2230 |
| N.W/G.W | KGS | 1950/2250 |
| Hercules Machinery Equipment Ltd. |
1. Feed motor: 3 axes using a 10N.m servo motor,auto-feed and change speeds variably (3 axes driven by one servo motor);
2. Work light: 1 set;
3. Draw bar: M16;
4. Milling arbor: 27mm;
5. Tools: 1 set;
